A. Pressure Bar Subassembly
ITEM
QTY.
NO.
1
1
TP-T1MB00029
2
1
TP-T1MB00030
3
1
TP-T1MB00031
4
2
TP-T1MB00068
5
1
TP-T1MB00111
6
1
TP-306002
7
4
TP-300001
8
2
TP-106093
9
4
TP-108155
10
2
TP-101130
P/N: TA-T10005
PART NO
DESCRIPTION
ANTI-JAM PRESSURE HOUSING
ANTI-JAM CONTACT STRIP
ANTI-JAM PRESSURE PAD
ANTI-JAM CONTACT STRIP
RUBBER STRIP HOLDER
RUBBER SEAL
RUBBER BUMPER
1/4-20 x 2" STUD
COMPRESSION SPRING
NUT, 1/4-20 ACORN HEX
132
