5.13 NBO Wide Seal Frame Assembly

ITEM
QTY.
NO.
1 1
2 1
3 1
4 1
5 2
5 2
5 2
6 2
7 2
7 2
7 2
8 2
9 1
10 1
11 1
12 1
13 1
14 1
15 1
16 1
17 2
18 1
19 1
20 1
21 1
21 1
21 1
22 1
23 2
24 1
25 2
26 1
27 2
28 2
129
P/N: TA-T10280-S18NB
PART NO
TP-T1-00200S18
TP-T1MB00010-W18
TP-T1MB00016-S18
TP-T1MB00005-W18
TP-T1MB00033-W18-1
TP-T1MB00033-W18-2
TP-T1MB00033-W18-3
TP-T1MB00057
TP-T1MB00144-1
TP-T1MB00144-2
TP-T1MB00144-3
TP-T1MB00022
TP-T1MB00164
TA-T10005-W18
TA-T10006-W18
TA-T10019
TA-T10019LH
TA-T10012-W18
TP-102109
TA-T10009
TP-T1MO00023-W18
TP-T1MB00063-W18
TA-T10017
TP-T1MB00107-S18
TP-403146
TP-403242
TP-403241
TA-T10020-S14
TP-403245
TP-T1MD00277NB-S18
TP-T1MD00276NB-S18-4
TP-T1MD00276NB-S18-2
TP-401257
TP-401277
DESCRIPTION
SEALER FRAME
SEALER ROD TIE BAR
SEAL CYLINDER MOUNTING BLOCK
FRONT GRIPPER PLATE
SEAL GUIDE ROD (5.25" Pass Through)
SEAL GUIDE ROD (6.25" Pass Through)
SEAL GUIDE ROD (7.25" Pass Through)
HEATER BAR YOKE
SHIELD MOUNTING ROD (5.25" PASS-THROUGH)
SHIELD MOUNTING ROD (6.25" PASS-THROUGH)
SHIELD MOUNTING ROD (7.25" PASS-THROUGH)
GUARD ROD MOUNTING BLOCK
PIVOT CLAMP
PRESSURE BAR SUB ASSEMBLY
HEATER BAR SUB-ASSEMBLY
NO HANDLE LATCH ASSEMBLY
LEFT HAND LATCH ASSEMBLY
GROOVED ROLLER MOUNT ASSY
HEAT TREATED WASHER
PTFE GUIDE SUB-ASSEMBLY
DROP FRAME SPACER
LATCH SHAFT
BAG FINGER GROUNDING ASSY
MAGNETIC SENSOR BLOCK
MAIN CYLINDER (5.25" PASS-THROUGH)
MAIN CYLINDER (6.25" PASS-THROUGH)
MAIN CYLINDER (7.25" PASS-THROUGH)
MANIFOLD ASSEMBLY
AIR CYLINDER
SHORT INTERNAL GUARD
GUARD BRACKET
NBO INTERNAL GUARD
ELBOW, 1/4" TUBE x 1/8 NPT
ELBOW 1/4" TUBE x #10-32
SEALER FRAME ASSEMBLY
