5.14 Electrical Panel

ITEM
QTY.
NO.
1 1
2 1
3 1
4 1
5 2
6 1
7 1
8 1
9 1
10 1
11 1
12 1
13 2
14 18
15 1
16 4
17 1
18 1
19 1
20 1
21 1
22 1
23 1
24 1
25 1
26 2
27 1
28 1
29 1
30 1
31 1
32 1
33 1
34 1
35 1
36 1
139
P/N: TA-T10270-S14
PART NO
TP-T1MC00006-S14
TP-205108
TP-207216, TP-207344
TP-212167
TP-212247
TP-212410
TP-213361
TP-215000A
TP-215000
TP-211386
TP-T1ME00301
TP-215384
TP-214279
TP- 208142
TP-218021
TP-214268
TP-215005
TP-T1MC00021
TP-212160
TP-T1MC00016S14
TP-212248
TP-218020
TP-220511, TP-214111,
TP-220513
TP-220514
TP-T1MO00228
TP-T1MO00229
TP-212166
TP-212338
TP-220508
TP-TP-212242
TP-215004
TP-215115 & 215116
TP-112240
TP-215400
TP-T1MC00002S14
TP-501169-1
DESCRIPTION
ELECTRONICS MOUNTING PANEL
EMI FILTER, CORCOM
FUSE HOLDER & FUSE
6-PIN CIRCULAR FEMALE
9-PIN D-SUB FEMALE
AC OUTLET
24VDC, 3AMP POWER SUPPLY
COVER
SOLID STATE RELAY
HIGH VOLTAGE TRANSFORMER
HIGH VOLTAGE BOARD
POWER SWITCH
STAND-OFF 1"
LARGE TERMINAL BLOCK
DIN RAIL
STAND-OFF .38"
SWITCH
TRANS MOUNTING PLATE
5-POS MINI DIM
ELECTRONICS MOUNTING BRACKET
25-PIN D-SUB FEMALE
DIN RAIL
PLC, BATTERY & COMM 2 CAS
PLC, FPO-E32T-A Expansion I/O
T-1000 EURO DISCONNECT SWITCH
STANDOFF
6-PIN MALE
10-PIN FEMALE
PLC ANALOG MODULE
3-PIN SOCKET W/ANGLE BRACKET
SWITCH KNOB
AUX RELAY & SOCKET
POWER CORD STRAIN RELIEF
ETHERNET COUPLER
ANGLE MOUNT 5-PHASE DRIVER
5-PHASE DRIVER
