5.1 T-1000-S14 Advanced Poly-Bagger

ITEM
QTY.
NO.
1 1
2 1
3 1
4 1
5 1
6 1
7 1
8 1
9 1
10 1
11 1
12 1
13 1
14 1
15 2
16 1
109
PART NO
TA-T10200
TA-T10210
TA-T10018
TA-T10220
TA-T10240
SEE ASSEMBLY
TA-T10250-S14
TA-T10001-S14
TA-T10280-S14
TA-T10002-S14
TA-T10270-S14
TP-T1MD00004-S14
TP-T1MD00005S14
TP-T1MD00044
TP-111241
SEE ASSEMBLY
T-T1000-S14
BASE ASSEMBLY
UPPER COLUMN ASSEMBLY
FLAT LOAD SHELF ASSEMBLY
DANCER ASSEMBLY
IOP (TOUCH SCREEN)
BAGGER W/OUT PRINTER
MAIN FRAME ASSEMBLY
AIR KNIFE ASSEMBLY
NBO SEAL DROP FRAME
UPPER ROLLER ASSEMBLY
ELECTRICAL PANEL
ELECTRONICS COVER
RIGHT SIDE COVER
TOP COVER
SNAP BUTTON PLUG
LEXAN GUARD W/SIDE GUARDS
DESCRIPTION
