Seal Time: The amount of time, in seconds, the heater bar will remain touching the surface of the bag for proper
sealing. To adjust this setting, press the <Seal Time> button, enter a value on the numeric keypad and then press
the <ENT> button.
Cool Time: The amount of time, in seconds, the pressure bar is released to ensure the seal is cool enough to be
torn off after the pressure bar and heater bar have come in contact with the bag. To adjust this setting, press the
<Cool Time> button, enter a value on the numeric keypad and then press the <ENT> button.
Note: The Seal Time and Cool Time work in conjunction with one another. The Cool Time cannot be set lower
than the Seal Time. For Example, if the Seal Time is set for 0.5, the Cool Time cannot be set lower than 0.5.
Index Delay: The amount of time, in seconds, the previous bag has to exit the seal area after it is released and the
next bag is fed into place. This delay prevents the next bag from feeding and prevents the seal bar from coming
into contact with the previous bag and causing a bag jam. To change this setting, press the <Index Delay> button,
enter a value on the numeric keypad and press the <ENT> button.

3.30 UF-5000 Infeed Conveyor Operation Screen

The UF-5000 is an optional conveyor available for purchase. If your machine or system includes a conveyor
please refer to the UF-5000 manual for further information.
3.31 BV-10 Barcode Verification Option
This option is purchased to validate that a barcode is present
and readable. See Figure 3 - 30.
Press the <ON> toggle button. For each barcode successfully
read, the status box will provide a "GOOD" message. If a
"NO READ" or "QUALITY" error occurs, a message will be
displayed. To reduce these error messages, APPI recommends
scanning the barcode before the bag is blown open when the
film is flat and under tension (not past the feed rollers.)
TEST: The Test button will test read a printed label. Testing
the printed label will ensure the bagger and Barcode Verifier
Figure 3 - 30
are calibrated correctly.
Reprint: The Reprint Toggle button can be used to reprint the previous label if the Barcode Verifier did not read.
If Reprint is turned ON, and the verifier records a "NO READ" error, the barcode verifier will automatically
rescan the label. If the bagger records "NO READ" after the rescan, the next bag is indexed with the same label
printed a second time. If the T-1000-S14 is running in Manual Mode, a warning screen will be displayed, and the
operator will have the option to reprint the label from that screen.
Quality Error: A STOP/CONTINUE toggle button to manage a "POOR QUALITY" read. When <CONTINUE>
is toggled, the "POOR QUALITY" reading will be ignored. When <STOP> is selected, the same sequence for the
Next Bag Reprint will be enabled.
Blower: Turns off the blower while setting up the Barcode Verifier.
