Power Supply Function
•
Voc: The open-circuit
voltage of the
battery.
•
CAP: Battery
capacity.
Open or select a user-defined battery
emulation file.
Set the file save
Recall File
address.
Edit a user-defined battery simulation
file.
Simulates the voltage
Full
value when the cell bat-
Voltage
tery is fully charged.
Simulates the voltage
Empty
value when the cell bat-
Voltage
tery is in the empty
state.
Simulates the internal
Inner
resistance of a cell
Resistance
battery.
Simulates the capacity
Capacity
of a cell battery.
Set the number of paral-
Parallel
lel connected batteries.
Set the number of bat-
Serial
teries in series.
Positive current limit val-
ue, which simulates the
I+
maximum discharge cur-
rent of the battery pack.
Negative current limit
value, which simulates
the maximum charge
I-
current of the battery
pack.
