CC
V-Rise Time/I-Rise Time
= 0.001s
V-Fall Time/I-Fall Time =
0.001s
Output Res
Sink Res
On Delay
Off Delay
Voltage Max
Copyright © Itech Electronic Co., Ltd.
Speed= High/Low
Constant current loop priority mode
Speed= High/Low
Displays the voltage or current rise time
setting according to the selected priority
mode. If CC priority mode is selected,
the parameter setting of I-Rise Time will
be displayed here.
Displays the voltage or current fall time
setting according to the selected priority
mode. If CC priority mode is selected,
the parameter setting of I-Fall Time will
be displayed here.
Set the internal resistance of the power
supply. This parameter needs to be set
only when Mode is set to CV.
Set the CR function in sink mode. This
parameter needs to be set only when
Mode is selected as CC.
•
OFF: Turn off the CR function.
•
ON: Turn on the CR function and set
Sink Res. Set Sink Res=0, which
means to turn off the CR function.
Set the delay time to turn on the output.
Set the delay time to turn off the output.
Set the upper limit of the voltage (de-
fault is the rated voltage of the instru-
ment). Once the voltage upper limit is
modified here, the parameters related
to the voltage setting will be limited by
the upper limit here.
Quick Reference
Loop response
speed setting:
high speed /
low speed
Loop response
speed setting:
high speed /
low speed
