time
end time Test time of end voltage, range:
count
Save To
File
User- Select the user-defined LV123 waveform.
de-
fined
Run Run the presently recalled waveform.
Open Recall the waveform saved inside the
instrument.
Recall
File
Edit Edit a user-defined waveform.
unlimit-
ed
upper-
limited
Copyright © Itech Electronic Co., Ltd.
Power Supply Function
Set the initial output voltage of the in-
strument before the LV123 regulation
waveform test. At the same time, this
value is also the end voltage after the
regulatory waveform test is
completed.
Test time of starting voltage, range:
0~999.999S.
0~999.999S.
Set the number of test repetitions,
ranging from 1 to 65535. The actual
number of test executions = count *
3.
Set the save address of the waveform
file, range: 1~10.
The address of the waveform file,
ranging from 1 to 10.
Range of unlimited operating capabil-
ity, with the following settings:
•
V1: Voltage in interval 1
•
V2: Voltage in interval 2
•
V3: Voltage in interval 3
•
V4: Voltage in interval 4
Range of upper limited operating ca-
pability, with the following settings:
•
V1: Voltage in interval 1
•
V2: Voltage in interval 2
•
V3: Voltage in interval 3
