When connecting the DUT (battery/capacitor), do not short-circuit
the battery/capacitor.
•
When connecting the DUT (battery/capacitor), it is recommended
that you purchase the IT-E165A anti-reverse connection and anti-
spark module to prevent the battery/capacitor reverse connection
that may cause damage to the instrument and spark during the bat-
tery/capacitor wiring; When there is no external auxiliary equipment
connected to prevent reverse connection and anti-spark function,
please pay attention to the safety of the wiring, and be careful not
to reverse the battery/capacitor connection, reverse connection will
cause damage to the instrument.
•
Before performing the battery test, you need to connect the Sense
cables to both ends of the battery. If the Sense cables are not con-
nected, the instrument cannot detect the Sense voltage and prompt
"Wait Power Link", which will prevent the battery test from
continuing.
BATTERY Battery charging/discharging test function
Run
Edit
Copyright © Itech Electronic Co., Ltd.
Indicates that the battery test mode is entered and
waits to trigger the running of the currently edited bat-
tery test file.
Edit the battery charging/discharging test file.
Charge /
Discharge
Power Supply Function
Set the test mode:
•
Charge: Battery charging
•
Discharge: Battery
discharging
According to the test require-
ments, choose one to set.
Set the voltage
Charge / value for charging
Discharge or discharging ac-
V cording to the se-
lected test mode.
Set the current val-
Charge /
ue for charging or
Discharge I
discharging
