M3903C-10-340 - ITech IT-M3900C Series User Manual

Power Factor
DC component
Current harmonics
Standard Interface
Command Re-
sponse Time
Parallel Number
Working
Temperature
Storage
Temperature
IP
Isolation DC to GND
Isolation AC to GND
Cooling
Dimension ( mm)
Weight( net)
6.1.2 IT-M3903C-10-340
Rated value
Setup Resolution
Parameter
Voltage
Current
Power
Resistance in series （CV
priority）
Load resistance （CC
priority）
Voltage
Current
Power
Resistance in series （CV
priority）
Load resistance （CC
priority）
Copyright © Itech Electronic Co., Ltd.
0.99
≤0.2A
≤3%
Standard: USB/LAN/CAN/IO
Optional: GPIB/Analog/RS232
0.1ms
≤16
0～40℃
-10℃～70℃
IP20
300Vdc
3500Vdc
Air
660mm*437mm*43.5mm
10kg
IT-M3903C-10-340
Technical Specification
0～10V
-240A～340A
-2400W～3400W
0～0.03Ω
0.006Ω～2Ω
0.001V
0.01A
1W
0.001Ω
0.001Ω
174
