6. Press the Left/Right key to select Run and press [Enter] to run the battery
7. Based on the selected trigger method, perform the trigger operation.
If you want to stop running during the battery test, you can do the following:
Press the composite keys [Shift]+[I-set] (Function) on the front panel to enter
the function menu.
At this point, the interface will prompt whether to stop the running of the Func-
tion, you can press the Left/Right key to select Stop, then the running will be
stopped, and the Function menu item will be displayed, you can re-enter the
Function menu for editing; if Reset is selected, it means to stop the present run-
ning and return to the main interface to wait for the next trigger operation.

4.6.3 Built-in Waveform Function

This series power supply supports built-in waveforms for user to execute the
test directly. The protocols/standards involved in the built-in waveforms include
the following:
•
•
•
•
•
•
test.
This product supports Sense anti-reverse function. If you reverse the
Sense cables, the VFD will display a negative voltage value, and you can-
not turn on the output at this time. It can only be turned on after the cables
are properly connected.
The trigger method of the battery test is consistent with the trigger method
of the List function, that is, the List trigger source is also effective for the
Battery function.
DIN40839
ISO16750-2
ISO21848
SAEJ1113–11
LV123
LV124
This series 10V model do not support built-in waveform function.
