Stop Running the Static PV Curve
If you want to stop running during the SAS test, you can do the following: Press
the composite keys [Shift]+[I-set] (Function) on the front panel to enter the
function menu.
At this point, the interface will prompt whether to stop the running of the Func-
tion, you can press the Left/Right key to select Stop, then the running will be
stopped, and the Function menu item will be displayed, you can re-enter the
Function menu for editing; if Reset is selected, it means to stop the present run-
ning and return to the main interface to wait for the next trigger operation.

4.6.5 Battery Simulation Function

This series power supply can simulate battery characteristics in practical appli-
cations based on its unique bidirectional properties and the variable output im-
pedance. You can set battery-related parameters to simulate the charge and
discharge characteristics of the battery to assist with other tests. The menu
items for this function are described below:
Battery
Emulator
5. Based on the selected trigger method, perform the trigger operation.
The trigger method of the SAS function is consistent with the trigger
method of the List function, that is, the List trigger source is also effec-
tive for the SAS function.
Battery simulation function
User-
define
Copyright © Itech Electronic Co., Ltd.
Select a user-defined battery simulation file for
testing.
Run the currently selected user-de-
Run
fined battery simulation file.
Initial Value
Power Supply Function
•
Set the initial state of
charge (SOC) of the
battery. 0~100% cor-
responds to the volt-
age range from no-
load voltage to full-
load voltage.
