Features

1.2 Features
The following table lists the features of COMX-CORE-2610-ET.
Table 1-1
Features
Processor / Memory Controller
PCH
BIOS Device
Memory
PCI Express x16
26
COMX-CORE-2610-ET Features Summary
Description
Intel Mobile processor Core i7-2610UE.
Integrated a dual channel 64bit DDR3 memory controller.
Memory capacity up to 8GB per channel, data rate up to
1333MHz and supports non-ECC.
Integrated Graphic process unit.
Supports DX10.1, DX10, and DX9.
Supports a PCI Express x16 interface, based-on PCI Express
2.0 specifications
Intel Mobile QM67 chipset.
Supports up to 8 x1 PCI Express interfaces.
Supports up to 2 SATA 6G and 4 SATA 3G.
Supports up to 14 USB 2.0.
Provide a LPC interface for TPM, FWH etc.
Provides a SM bus, it is I2C compatible.
Provides 2 chip select of SPI.
SPI frequency is 20MHz or 33MHz.
Provides a HD audio interface.
Supports VGA + LVDS display interface.
Supports 3 digital display interfaces.
One piece of 16MB SPI boot devices
Supports up to 8GB non ECC DDR3 memory per DIMM.
Supports DDR3 memory data transfer rates of 1066 MT/s and
1333 MT/s.
Supports x8 and x16-bit DDR3 chip.
Supports 2 SODIMM.
A PCI Express x16 interface is routed to connector and it can
be configured as:
1 PCI Express x16
2 PCI Express x8
2 PCI Express x4 plus 1 PCI Express x8
