4.6

System Memory

There are two 204-pin SODIMM slots on COMX-CORE-2610-ET board. They stack on the
top of PCB.
The following table lists the DDR3 (1.5V) memory banks that have been validated on the
COMX-CORE-2610-ET board.
Supplier
Virtium
Virtium
Viking
Viking
Viking
Virtium
Virtium
4.7

PCI Express X16 Interface

The PCI Express port(s) are fully-compliant with the PCI Express Base Specification,
Revision 2.0. The following table describes the PCI Express x16 interface configuration.
Table 4-1
Configuration
1
2
3
COMX-CORE-2610-ET Installation and Use (6806800P11E)
Supplier Part
Number
VL47B1G63D-K9SA
VL47B5663D-K9SG
VR7PU126458GBDHB
VR7PU566458GBDHB
VR7PU286458FBDHT
VL47B5663D-K0MG
VL47B5263D-K9SD-S1
PCI Express x16 Interface Configuration
Organization
1x8
2x4
2x8
1x16
System Memory
Specifications
DDR3-1333 8GB SODIMM Non-ECC
DDR3-1333 2GB SODIMM Non-ECC
DDR3-1333 4GB SODIMM Non-ECC
DDR3-1333 2GB SODIMM Non-ECC
DDR3-1333 1GB SODIMM Non-ECC
DDR3-1600 2GB SODIMM Non-ECC
DDR3-1333 4GB SODIMM Non-ECC
(ET version)
Mobile
Graphics
I/O
Graphics, I/O
Graphics, I/O
57
