I2C Serial Interface and Device
The following diagram shows the SM bus device connection.
Figure 4-2
Device
Address
A8
A0
A4
56
56
Board SM Bus Device Connection Diagram
Device
Device
Description
AT24C02C
2Kbit EEPROM
SPD0
DDR3 DIMM0 SPD DIMM0 SPD information
SPD1
DDR3 DIMM1 SPD DIMM1 SPD information
NCT7802Y
EC controller
COMX-CORE-2610-ET Installation and Use (6806800P11E)
Functional Description
Remark
Factory Data, should not be modified
by the customer unless instructed
EC software code
