Table 3-1 Com Express Connector Pin Assignment - SMART Embedded Computing COMX-CORE-2610-ET Installation And Use Manual

Table 3-1
PIN Number
A5
A6
A7
A8
A9
A10
A11
A12
A13
A14
A15
A16
A17
A18
A19
A20
A21
A22
A23
A24
A25
A26
A27
COMX-CORE-2610-ET Installation and Use (6806800P11E)
COM Express Connector Pin Assignment (continued)
PIN Name
GBE0_LINK1000#
GBE0_MDI2-
GBE0_MDI2+
NC
GBE0_MDI1-
GBE0_MDI1+
GND (FIXED)
GBE0_MDI0-
GBE0_MDI0+
GBE0_CTREF
SUS_S3#
SATA0_TX+
SATA0_TX-
SUS_S4#
SATA0_RX+
SATA0_RX-
GND (FIXED)
SATA2_TX+
SATA2_TX-
SUS_S5#
SATA2_RX+
SATA2_RX-
BATLOW#
COM Express Connectors
PIN Number
B5
B6
B7
B8
B9
B10
B11
B12
B13
B14
B15
B16
B17
B18
B19
B20
B21
B22
B23
B24
B25
B26
B27
PIN Name
LPC_AD1
LPC_AD2
LPC_AD3
LPC_DRQ0#
LPC_DRQ1#
LPC_CLK
GND (FIXED)
PWRBTN#
SMB_CK
SMB_DAT
SMB_ALERT#
SATA1_TX+
SATA1_TX-
SUS_STAT#
SATA1_RX+
SATA1_RX-
GND (FIXED)
SATA3_TX+
SATA3_TX-
PWR_OK
SATA3_RX+
SATA3_RX-
WDT
41
