SMART Embedded Computing COMX-P40x0 ENP2 Quick Start Manual

COMX-P40x0 ENP2
Quick Start Guide
P/N: 6806800R98C December 2019
1 Box contents
Make sure you receive all items of your shipment:
• One COMX-P40x0 ENP2
• One printed copy of Quick Start Guide (this document)
• One printed copy of Safety Notes Summary
When installing or servicing the system or accessories,
strictly observe the safety precautions in the Safety Notes
Summary. Ignoring these instructions can void the system
warranty and cause personal injury or property damage.
2 ESD
Electrostatic discharge and incorrect installation or
removal of the card can damage circuit or shorten its life.
Use a properly grounded ESD wrist strap or work in an
ESD-safe environment.
Connect to the ESD connector at the front or the rear of
the system.
3 Site preparation
1. Make sure that all environmental and power requirements
defined in the COMX-P40x0 ENP2 Installation and Use
manual are met.
2. Operating temperatures refer to the temperature of the air
circulating around the blade and not to the actual component
temperature.
For more information about connecting cables and power cords,
refer to the COMX-P40x0 ENP2 Installation and Use manual.
4 Install the COMX-P40x0
ENP2
1. Line up the board-to-board connector of the module assembly
with the board-to-board connector of the carrier board.
2. Make sure that the interconnectors are properly aligned and that
the five standoffs on the module have contact with the top of the
carrier board.
3. From the bottom side of the carrier board, locate the screw holes
on module and carrier board.
4. Use the screws to fasten the module to the carrier board.
Note: This installation procedure is only for reference. Assemble the
heat sink and the module based on your own thermal solution.
Technical Assistance
For technical assistance or to report product damage or shortages,
contact your local SMART Embedded Computing sales
representative or visit https://www.smartembedded.com/ec/support/
Get More Information
For more information on this product, see the
COMX-P40x0 ENP2 Installation and Use manual and
other related technical documentation, which can be
found by using the Documentation Search at
https://www.smartembedded.com/ec/support/.
