COM Express Connectors
Table 3-1
PIN Number
A75
A76
A77
A78
A79
A80
A81
A82
A83
A84
A85
A86
A87
A88
A89
A90
A91
A92
A93
A94
A95
A96
A97
A98
44
COM Express Connector Pin Assignment (continued)
PIN Name
LVDS_A2+
LVDS_A2-
LVDS_VDD_EN
LVDS_A3+
LVDS_A3-
GND (FIXED)
LVDS_A_CK+
LVDS_A_CK-
LVDS_I2C_CK
LVDS_I2C_DAT
GPI3
RSVD
RSVD
PCIE0_CK_REF+
PCIE0_CK_REF-
GND (FIXED)
SPI_POWER
SPI_MISO
GPO0
SPI_CLK
SPI_MOSI
TPM_PP
TYPE10#
SER0_TX
COMX-CORE-2610-ET Installation and Use (6806800P11E)
PIN Number
B75
B76
B77
B78
B79
B80
B81
B82
B83
B84
B85
B86
B87
B88
B89
B90
B91
B92
B93
B94
B95
B96
B97
B98
Controls, LEDs, and Connectors
PIN Name
LVDS_B2+
LVDS_B2-
LVDS_B3+
LVDS_B3-
LVDS_BKLT_EN
GND (FIXED)
LVDS_B_CK+
LVDS_B_CK-
LVDS_BKLT_CTRL
VCC_5V_SBY
VCC_5V_SBY
VCC_5V_SBY
VCC_5V_SBY
BIOS_DISABLE1#
VGA_RED
GND (FIXED)
VGA_GRN
VGA_BLU
VGA_HSYNC
VGA_VSYNC
VGA_I2C_CK
VGA_I2C_DAT
SPI_CS#
RSVD
