GPIO
GPO
I2C
IDE
LPC
LVDS
PCI
PCIE
PHY
Pin-out Type
SPD
S0, S1, S2, S3, S4, S5
SATA
SDVO
Super I/O
HDMI
12
General Purpose Input Output.
General Purpose Output.
Inter Integrated Circuit - 2 wire (clock and data) signaling scheme
allowing communication between integrated circuits, primarily used to
read and load register values.
Integrated Device Electronics - parallel interface for hard disk drives -
also known as PATA.
Low Pin-Count Interface: a low speed interface used for peripheral
circuits such as Super I/O controllers, which typically combine legacy-
device support into a single IC.
Low Voltage Differential Signaling - widely used as a physical interface
for TFT flat panels. LVDS can be used for many high-speed signaling
applications. In this document, it refers only to TFT flat-panel
applications.
Peripheral Component Interface.
Peripheral Component Interface Express - next-generation high speed
Serialized I/O bus.
Ethernet controller physical layer device.
A reference to one of five COM Express definitions for what signals
appear on the COM Express module connector pins.
Serial Presence Detect - refers to serial EEPROM on DRAMs that has
DRAM module configuration information.
System states describing the power and activity level.
S0 Full power, all devices powered S1 S2 S3 Suspend to RAM System
context stored in RAM; RAM is in standby.
S4 Suspend to Disk System context stored on disk.
S5 Soft Off Main power rail off, only standby power rail present.
Serial AT Attachment: serial-interface standard for hard disks.
Serialized Digital Video Output - Intel defined format for digital video
output that can be used with Carrier Board conversion ICs to create
parallel, TMDS, and LVDS flat panel formats as well as NTSC and PAL
TV outputs.
An integrated circuit; typically interfaced via the LPC bus that provides
legacy PC I/O functions including PS2 keyboard and mouse ports, serial
and parallel port(s) and a floppy interface.
High Definition Multimedia Interface.
