Table 3-2 Com Express Connector Pin Assignment (Continued) - SMART Embedded Computing COMX-CORE-2610-ET Installation And Use Manual

Table 3-1
PIN Number
A99
A100
A101
A102
A103
A104
A105
A106
A107
A108
A109
A110
Table 3-2
PIN Number
C1
C2
C3
C4
C5
C6
C7
C8
C9
COMX-CORE-2610-ET Installation and Use (6806800P11E)
COM Express Connector Pin Assignment (continued)
PIN Name
SER0_RX
GND (FIXED)
SER1_TX
SER1_RX
LID#
VCC_12V
VCC_12V
VCC_12V
VCC_12V
VCC_12V
VCC_12V
GND (FIXED)
COM Express Connector Pin Assignment (continued)
PIN Name
GND (FIXED)
GND
NC
NC
GND
NC
NC
GND
NC
COM Express Connectors
PIN Number
B99
B100
B101
B102
B103
B104
B105
B106
B107
B108
B109
B110
PIN Number
D1
D2
D3
D4
D5
D6
D7
D8
D9
PIN Name
RSVD
GND (FIXED)
FAN_PWMOUT
FAN_TACHIN
SLEEP#
VCC_12V
VCC_12V
VCC_12V
VCC_12V
VCC_12V
VCC_12V
GND (FIXED)
PIN Name
GND (FIXED)
GND
NC
NC
GND
NC
NC
GND
NC
45
