SMART Embedded Computing COMX-CORE-2610-ET Installation And Use Manual page 27

Table 1-1
Features
HD Audio
PCI Express
SATA
USB
Ethernet
Display
LPC
SM bus
Watchdog
Form Factor
Miscellaneous
COM Express
COMX-CORE-2610-ET Installation and Use (6806800P11E)
COMX-CORE-2610-ET Features Summary (continued)
Description
A HD Audio interface is routed to connector.
7 x1 PCI Express or 1 x4 + 3 x1 PCI Express interfaces are
routed to connector.
Two SATA 6G and 2 SATA 3G ports are routed to connector.
Eight USB 2.0 ports are routed to connector.
A Gigabit Ethernet is routed to connector (82579).
A VGA interface routed to connector.
A dual channel LVDS interface is routed to connector.
1 digital display interface is routed to connector and it can be
used as DP/HDMI/DVI/SDVO.
2 digital display interface are routed to connector and they
can be used as DP/HDMI/DVI.
A LPC interface is routed to connector.
SM bus is routed to connector, it is I2C compatible.
The Watchdog is integrated in QM67.
COM Express basic form factor, 95mm x 125mm.
One 26-pin XDP header for CPU debug.
Basic form factor as defined in the PICMG COM.0 COM
Express Basic Specification Revision 2.0.
COM Express Type 6 pin-out.
Board-to-board interconnectors comprising two 220-pin,
0.5mm pitch Receptacles.
Features
27
