Connectors and Switches

Figure 3-2
3.1 Connectors and Switches
3.1.1

COM Express Connectors

COMX-CORE-2610-ET supports Type 6 COM Express connector definition. The signals
from COM Express connector are based COM-E SPEC2.0 standard. This section
describes the COM Express connector used on the board. The following table lists the
signals definitions.
Table 3-1
PIN Number
A1
A2
A3
A4
40
COMX-CORE-2610-ET Board Layout (Bottom view)
COM Express Connector Pin Assignment
PIN Name
GND (FIXED)
GBE0_MDI3-
GBE0_MDI3+
GBE0_LINK100#
COMX-CORE-2610-ET Installation and Use (6806800P11E)
PIN Number
B1
B2
B3
B4
Controls, LEDs, and Connectors
PIN Name
GND (FIXED)
GBE0_ACT#
LPC_FRAME#
LPC_AD0
