Table 5-16 IGD Configuration

Field
IGD - Boot Type
IGD - Secondary Boot
Type
IGD - LCD Panel Type
IGD - Active LFP
Panel Color Depth

Table 5-17 South Bridge Configuration

Field
State After G3
LID# Function
Sleep# Function
Onboard TPM
SB USB Config
SB Azalia Config
74
Description
Select the video device activated which will be activated during POST.
This has no effect if external graphics present. Secondary boot display
selection will appear based on your selection. VGA modes will be sup-
ported only on primary display. CRT is for Onboard VGA, EFP is for
Integrated Display port, LFP is for Internal LVDS/eDP, CRT2 is for
SDVO to VGA transition device, EFP2 is for Integrated HDMI, Default
setting is CRT.
Select secondary display device. CRT is for Onboard VGA, EFP is for
Integrated Display port, LFP is for Internal LVDS/eDP, CRT2 is for
SDVO to VGA device, EFP2 is for Integrated HDMI, Default setting is
LFP.
Select the video device which will be activated during POST. This has
no effect if external graphics are present. Default setting is 1024 x 768
LVDS Color Panel.
Select the active LFP configuration. Default setting is Int-LVDS.
Select the LFP panel color depth, Default setting is 24 Bit.
Description
Specify what state to switch to when power is re-applied after a power
failure (G3 State). Default setting is State S0.
Enable or Disable LID# function, Default setting is Disabled.
Enable or Disable Sleep# function, Default setting is Disabled.
Enable or Disable Onboard TPM module. Default setting is Enabled.
Set USB configuration.
Set HD Audio configuration.
