Table 5-18 SB USB Configuration

Field
EHCI1
EHCI2
USB Ports Per-Port
Disabled Control
USB Port
#0/1/2/3/4/5/6/7/8/9/10/11
/12/13
Enable/Disable

Table 5-19 SB Azalia Configuration

Field
Azalia
Azalia internal HDMI codec

Table 5-20 Network Configuration

Field
PCH Internal LAN
LAN OPROM Selection
Wake on PCH LAN

Table 5-21 Hardware Monitor

Field
CPU Temperature
Local Temperature
COMX-CORE-2610-ET Installation and Use (6806800P11E)
Description
Control the USB EHCI (USB 2.0) functions. Default setting is Enabled.
Control the USB EHCI (USB 2.0) functions. Default setting is Enabled.
Controls each of the USB ports (0~13) enable/disable. Default setting is
Disabled.
Enable/Disable USB port. Default setting is Enabled.
Description
Control detection of the Azalia device. Default setting is Auto.
Enable/Disable internal HDMI codec. Default setting is Enabled.
Description
Enable/Disable PCH Internal LAN. Default setting is Enabled.
This is used to select LAN OPROM for quick boot minimal configuration.
Default setting is Enabled.
Enable PCH Internal wake on LAN capability. Default setting is
Disabled.
Description
Showing CPU Temperature
Showing local temperature
Advance Menu
