JMA AVANTCODE User Manual page 69

P7 P8
Fig.57
Fig.56
P9 P10
Fig.58
6.9 REPLACING THE LEDS
1) Turn the machine off at the main switch and disconnect the power cable.
2) Unscrew the 6 screws fastening the "rear motor casing". The screws are on the right and
left sides, the upper and lower sections.
3) Release the two power strip cables (P11), by releasing the two screws (T29). (Fig.59)
4) Release the LEDS base, by unscrewing the two screws (T30). (Fig.58)
5) Release the two LED holders (P12) by unscrewing the two screws (T31). (Fig.59)
6) Replace and fasten the LEDS with both holders.
7) Screw in the LEDS base.
8) Finally connect the cables to the power strip.
63
