8. Continue as follows (Fig.39):
• If X is not 0, loosen the screw (T12) and use the 2 Allen key to advance or go back
according to the directions indicated on the display, by turning the screw (T13).
(NB: Turning the screw (T13) a quarter turn produces a 13 hundredths of a millimeter movement).
• If Y is not 0, loosen the screw (T14) and use the 2 Allen key to advance or go back
according to the directions indicated on the display, turning the screw (T15).
(NB: Turning the screw (T15) a quarter turn produces a 13 hundredths of a millimeter movement).
9. Fasten the (T12 / T14) screw and press START.
10. Once the milling tool has been calibrated, the following message appears for a moment,
and then the screen returns to the calibration menu.
(NB: Differences of +-
axes are acceptable).
(NB: By pressing ENTER, the machine saves the adjusted values that the operator has just
calibrated)
And finally, analyze the feeder calibration.
CALIBRATE FEEDER
1. Select the Calibrate feeder icon.
2. The display reads:
3. Open the clear shield and position the calibration template (CRG) in the feeder. (See
section 3.2.2, Fig.21, Fig.22).
4. Close the shield and press START.
5. A "processing" message appears.
6. Once the cycle completes, the following message appears for a moment, and then the
screen returns to the calibration menu.
Saving information !!!
CALIBRATE FEEDER
Milling tool FP16W
Clamp Auto
START Load part
0.02 mm on the X and Y
