JMA AVANTCODE User Manual page 47

•
Probe: ENABLE/DISABLE: Enables/disables reading the key using a
laser sensor.
•
Adaptor: Adapter reference (if required).
•
Milling machine: Milling machine used to cut the key. The machine comes
fitted with the FP16W milling tool, which can be used for all flat keys. If you
are using a special key type and need another milling tool, add the
corresponding reference here.
(NB: The Avantcode cannot use any milling tools that have not been specially
designed for it and supplied by JMA)
•
Clamp: Standard clamp reference. The machine comes equipped with the MP1
clamp. See section 4.1.1
•
Key tip: See section 4.1.1
•
Clamp tip: See section 4.1.1
•
Clamp side: See section 4.1.1
The second table,
6.
•
Key width: The keyblank width.
•
Y current: Y position, where the reference for the electricity contact is taken.
•
Type of cut: (See section 3.4.)
•
Angle: Key bitting angle.
•
Supports: Number of pins or teeth on the key.
•
Speed: The cutting speed of the machine carriages.
•
Number of sides: The number of sides to be cut, if the key is defined as
having two sides, the machine asks which file is to be used to cut side B. If
it's a symmetrical key (LMec.2) use the same file name as the file being
created. If it's asymmetrical (LMec.3), the name of the file to be used to cut
side B must be entered.
The third table Symbols/Depth: is for the cut depth. Each symbol is given a depth.
7.
The fourth table, Spaces: is the distance between the key's teeth or pins.
8.
This data is defined in the following manner:
•
First space = from the collar of the key to the first pin or support.
•
The following spaces refer to the relative spaces between the pins. I.e. the
spaces between the supports or indents.
•
If the tip is pointed, an extra space needs to be added - the distance between the
top and the last support on the key.
EDIT FILES
Symbol./Depth:
--/------- --/------
--/------- --/------
EDIT FILES
Probe ENABLE
Adapter ------
Milling tool FP16
Clamp MP1
Key stop C
Clamp stop 1
Clamp side 1
EDIT FILES
Key width ------
Y current ------
Type of cut
NORMAL
Angle ---
Supports --
Speed -
Number of sides -
41
