3.2

AVANTCODE (KEY FEEDER)

3.2.1

USING THE AUTOMATIC CLAMP

Place the keys in the automatic clamp using the key feeder. The key leaves the feeder as the
carriages move, the back of the key is positioned on the lower jaw of the automatic clamp and
once in position, the upper jaw comes down to clamp the key. The upper jaw is raised and
lowered by an electric motor.
Keys that can be cut in the automatic clamp:
•
Key thickness: 1.8 - 2.8 mm
•
Max. cutting depth: 3.9 mm.
•
Keys cut down one side.
Keys that cannot be cut:
Keys with a plastic bow, cross keys and pointed tip.
1.
The required parameters enabling you to use the key feeder to cut a key are specified in the
image below (Fig.20).
Max.28
Max.40 Min.15
Fig.20
Max.40 Min.20
Max.12 Min.6
