2.6

TECHNICAL INFORMATION

The main technical information is set out below:
Motor........................ ..........................Single phase 220V, 50 Hz, 0.25 Kw, 3000 rpm, 2.04
Amp.
Milling.......................... Widia
Speed.......................... 1500 rpm.
Clamps........................ Four faced.
Movement.................... Via ball spindles activated by stepper motors on
Strokes.................... X= 40 mm.
Light...................................... LED
Dimensions............................ Depth: 650 mm, Width: 495 mm, Height: 420 mm.
Display screen........................ 5.7" LCD Touch Screen.
Weight................................... 55 kg
CLASS 1 LASER DEVICE
•
Maximum radiation excluding safety block: 200 μW
•
Wavelength: 780 nm (not visible)
•
Classified according to: EN 60825-1:1994 + E.C.1995 + A1:2002 + A2:2001
∅
70 x 16 x 5.25 mm.
roller guides.
Y= 100 mm.
