2.5.2

AVANTCODE (KEY FEEDER)

13
4
21
15
1. Milling Tool.(Fig.4).
2. Mill protector. (Fig.4)
3. Automatic clamp.
4. Loading unit.
5. Reader clamp.
6. X carriage.
7. Y carriage.
8. Protective shield.
9. Keyboard.
10. Display screen.
11. Laser reader. (Fig.4)
12. Shavings box.
13. Light.
14. Emergency button.
15. Mat.
16. Serial line cable (RS-232).
17. Socket.
18. On/off switch.
19. USB.
20. Ethernet
21. Key box.
8
3
5
6
7
12 10
16
14
9
20 19
Fig.5
17 18
6
