JMA AVANTCODE User Manual page 20

• Key stop.
Once you have selected the side of the clamp, position the key lengthwise, bearing in mind the
key stop. There are two types of stop, depending on the key model:
Collar stop (C): This is the most common type. The key is stopped by mechanically
1.
blocking the clamp (Fig.14)
Pointed tip (1, 2, 3): The key tip is produced using the tip stop supplied as an accessory,
2.
which is placed in the standard clamp slot beside the key.
Example of a
(Fig.15)
Tip stop
Fig.14
key placed in side 1 and tip 2
14
