Part 3.9: Hdmi Input Interface - Alinx ZYNQ UltraScale+ User Manual

HDMI_D1
HDMI_D2
HDMI_D3
HDMI_D4
HDMI_D5
HDMI_D6
HDMI_D7
HDMI_D8
HDMI_D9
HDMI_D10
HDMI_D11
HDMI_D12
HDMI_D13
HDMI_D14
HDMI_D15
HDMI_D16
HDMI_D17
HDMI_D18
HDMI_D19
HDMI_D20
HDMI_D21
HDMI_D22
HDMI_D23
HDMI_SCL
HDMI _SDA

Part 3.9: HDMI Input Interface

HDMI input interface, using ADV7611 decoder chip from ANALOG
DEVICE, supports up to 1080P@60Hz input and supports data output in
different formats. The IIC configuration interface of ADV7611 is also connected
to the IO of ZU4EV PL. ZYNQ initializes and controls ADV7611 through I2C bus
programming. The hardware schematic of the HDMI input interface is shown in
Figure 3-9-1.
48 / 66
ZYNQ Ultrascale + FPGA Board AXU5EV-P User Manual
B35_L22_N
B35_L22_P
B35_L20_N
B35_L20_P
B35_L19_N
B35_L19_P
B35_L24_N
B35_L24_P
B35_L4_P
B35_L1_N
B35_L1_P
B35_L16_N
B35_L16_P
B35_L18_N
B35_L18_P
B35_L15_N
B35_L15_P
B35_L7_N
B35_L7_P
B35_L6_N
B35_L6_P
B35_L17_P
B35_L17_N
B35_L13_N
B35_L13_P
B11 HDMI Video Signal Data1
C11 HDMI Video Signal Data2
B12 HDMI Video Signal Data3
C12 HDMI Video Signal Data4
C13 HDMI Video Signal Data5
C14 HDMI Video Signal Data6
A12 HDMI Video Signal Data7
A13 HDMI Video Signal Data8
J14 HDMI Video Signal Data9
L14 HDMI Video Signal Data10
L15 HDMI Video Signal Data11
C16 HDMI Video Signal Data12
D16 HDMI Video Signal Data13
A17 HDMI Video Signal Data14
B17 HDMI Video Signal Data15
E17 HDMI Video Signal Data16
F17 HDMI Video Signal Data17
G16 HDMI Video Signal Data18
G17 HDMI Video Signal Data19
H16 HDMI Video Signal Data20
J16 HDMI Video Signal Data21
C17 HDMI Video Signal Data22
B16 HDMI Video Signal Data23
E15 HDMI IIC Control Clock
E16 HDMI IIC Control Data
