Among them, the IO level standard of BANK43~46 is 3.3V, and the
level standard of BANK65 and BANK66 is determined by the VCCO_65
and VCCO_66 power supply of the carrier board, but cannot exceed +1.8V;
the level standard of MIO is also 1.8V.
Pin assignment of board to board connector J29
J29 Pin Signal Name
1 B65_L2_N
3 B65_L2_P
5 GND
7 B65_L4_N
9 B65_L4_P
11 GND
13 B65_L1_N
15 B65_L1_P
17 GND
19 B65_L7_P
21 B65_L7_N
23 GND
25 B65_L15_P
27 B65_L15_N
29 GND
31 B65_L16_P
33 B65_L16_N
35 GND
37 B65_L14_P
39 B65_L14_N
41 GND
43 B65_L5_N
45 B65_L5_P
47 GND
49 B65_L11_N
51 B65_L11_P
53 GND
30 / 66
ZYNQ Ultrascale + FPGA Board AXU5EV-P User Manual
Pin Number J29 Pin
V9
U9
-
T8
R8
-
Y8
W8
-
L1
K1
-
N7
N6
-
P7
P6
-
M6
L5
-
T7
R7
-
K3
K4
-
Signal Name
2 B65_L22_P
4 B65_L22_N
6 GND
8 B65_L20_P
10 B65_L20_N
12 GND
14 B65_L6_N
16 B65_L6_P
18 GND
20 B65_L17_P
22 B65_L17_N
24 GND
26 B65_L9_P
28 B65_L9_N
30 GND
32 B65_L3_N
34 B65_L3_P
36 GND
38 B65_L19_P
40 B65_L19_N
42 GND
44 B65_L18_P
46 B65_L18_N
48 GND
50 B65_L8_P
52 B65_L8_N
54 GND
Pin Number
K8
K7
-
J6
H6
-
T6
R6
-
N9
N8
-
K2
J2
-
V8
U8
-
J5
J4
-
M8
L8
-
J1
H1
-
