CKD MN4KB2 Series Instruction Manual page 40

８
SPECIFICATION
HOW TO ORDER
8.3 Accessory
1) End block (NE)
2) Air supply exhaust block (NQ)
[SM-213928-A/2]
Model no.
N4KB2-NE1 Left-side end block
Model no.
N4KB2-NE2 Right-side end block
Model no.
N4KB2-2NQSH12
N4KB2-2NQSH10
N4KB2-2NQSH8
Model no.
N4KB2-2NQUH12
N4KB2-2NQUH10
N4KB2-2NQUH8
―39―
Description
Description
P port R port
φ12 φ12
φ10 φ10
φ8 φ8
P port R port
φ12 φ12
φ10 φ10
φ8 φ8
