4.4 Wiring

WARNING  :

CAUTION  :
1)
Caution for wiring
(1) When using the small terminal box and water-proof is required, use cab-tire
cords φ4 to φ6.5 in outer diameter (water-resistance is improved, but not
for outdoor use).
(2) The connector type (C, C1, C2, C3, D, D1, D2, D3) should be used in a place
with little dust and not directly exposed to water and oil.
(3) For the electrical circuit, use a switching circuit free of chattering.
(4) The electrical circuit should have fuses.
(5) Be sure that the operation voltage is within 10% of the rated voltage.
Before wiring, read the instruction manual carefully and
understand the instructions.
A person who wires needs to have knowledge for safely
performing  such operation based on the understanding
about the  mechanisms and operating principles of sole-
noid valves.
Before  supplying  the  power,  check  the  power  supply
voltage and the current type (AC or DC).
−18−
INSTALLATION
[SM-213928-A/2]
