8. PRODUCT SPECIFICATIONS AND HOW TO ORDER
8.1 Product Specifications
1) Specifications of the Block Manifold
Manifold
Applicable solenoid valve
No. of stations
Valve type and operation
Working fluid
Piping method(Note1)
Air supply exhaust P・R
Port size
Cylinder port A・B
Tube to be used
Flow characteristics C(Sonic conduct-
ance)
Ambient temperature
Fluid temperature
Min. working pressure
Max. working pressure
Proof pressure
Response time
Lubrication
Protection structure
Vibration resistance
Shock resistance
Atmosphere
Manual operating device
Above-mentioned response time is the figure on the non-lubricated at 0.5 MPa ,
and depends on the pressure and quality of lubricant.
Pressure is converted as 1MPa=10.1972kgf/cm
In case of use, consult separately of the continuous energizing.
Note1:Common pilot exhaust(except pilot exhaust of 3-position)
2) Electrical Specifications
Rated voltage
Starting current
Holding current
Power consumption (with indicator
light)
Voltage fluctuation range
Thermal class
Temperature rise
Electric connection
[SM-213928-A/2]
Item
dm
/(s・bar)
3
℃
℃
MPa
0.15(2-pos.single)
MPa
MPa
ms
Not required (Use Grade turbine oil type 1. ISO VG 32 when required)
m/s
2
m/s
2
Item
V
AC100V (50 / 60Hz)
A
A
W
℃
Specifications
Block manifold (DIN rail mount)
(N) 4KB2 Series (not including the external pilot series)
Pilot operated soft spool valve
Compressed Air
Common air supply (P), common exhaust (R)
Top (φ8, φ10、φ12 push-in joint)
Side (φ6, φ8, φ10 push-in joint)
Soft nylon (F-15 Series)
Urethane (U-95 Series), New urethane (UN Series)
4KB210,4KB220:2.6
4KB230:2.4
4KB240:3.1
4KB250:2.3
0.10(2-pos.double)
30 or less(2-pos)
No corrosive gas should exist
Non-locking type (Option : locking)
2
2
≒10.2kgf/cm
Specifications
AC200V (50 / 60Hz)
0.056 / 0.044
0.028 / 0.022
0.028 / 0.022
0.014 / 0.011
1.8 / 1.4 (1.8 / 1.5)
B(mold coil)
Grommet with lead wire
(option : small terminal box, C-connector, D-connector)
―35―
2 to 25
5 to 50
5 to 50
0.20(3-pos.)
0.70
1.05
60 or less(3-pos)
Dust-proof
50 or less
300 or less
DC24V
1.8 (2.0)
±10%
43
0.075
