Plug-in connector D type
Name
with lead wire
Option
D
code
Lead wire 300mm
(11/0.16)
Shape
Circuit
Name
Surge suppressor attached
Option
code
DC(only grommet lead
wire)
Shape
The surge suppressor
has polarity
Red
(+)
Circuit
(−)
Black
Plug-in connector D type
without lead wire
D1
S
AC,DC(other than
grommet lead wire type)
(〜)
(〜)
−20−
Plug-in connector D type
with lead wire,
surge suppressor and
indicator light
D2
Lead wire 300mm
(11/0.16)
(〜)
AC
(〜)
(
)
DC
(
)
INSTALLATION
Plug-in connector D type
without leadwire,
surge suppressor and
indicator light
D3
Red
Black
[SM-213928-A/2]
