2.4.4

Outputs 7 and 8

Outputs 7 and 8 are programmable and provide a combined output of 1 A. Each
individual output is capable of providing:
•
•
Note:
Figure 15 shows a camera powered by output 8 and activated by output 1.
2.5

Connecting the Card Reader

The card readers are manufactured by AWID and are part of the Mircom Card
Access package. The cards are produced by Mircom. The controller supports
two card readers.
2.5.1

Card Reader Requirements

Mircom provides the SR-2400MI-GR-MP multi protocol proximity card reader.
Third party card readers must meet the following minimum requirements in order
to be compatible with Mircom's card access system:
•
•
•
•
•
Version 1.00.3 TX3-CX Card Access System Installation and Operation Manual
Copyright 2009
12 Vdc
500mA of current (700 mA maximum)
Outputs 7 and 8 are capable of providing a maximum output of
700 mA each, for a combined output of 1 A. For example, if
output 7 provides 700 mA, then output 8 provides 300 mA.
Camera
12V
OUTPUT 7

Figure 15. Controller 12 V Output Sample Connections

must support the 26 bit standard SIA protocol
standard Wiegand interface
LED status indicator
warning or alarm buzzer
12 Volt operation
NC C NO NC C NO
12V
OUTPUT 8
OUTPUT 1
Installation and Setup
27 (56)
