3.2

Correlation

The configurator software correlations function lets you establish specific
relationships between panel inputs (events) and outputs (actions). Correlations
also allow you to specify these relationships to a schedule.
3.2.1

Assigning events to access points

Assigning events to access points associates the access point with the event. The
configurator lets you assign input events by labelling the following access points:
•
•
•
3.2.2

Events

Events are defined by the following inputs and reader states:
•
•
•
•
•
•
•
•
•
•
3.2.3

Actions

An action is defined by the type of action that occurs for a specific event and
consists of the following:
•
•
•
•
Version 1.00.3 TX3-CX Card Access System Installation and Operation Manual
Copyright 2009
Reader A
Reader B
Inputs 1 to 8
Access is granted (from Reader A or B)
Access is denied (from Reader A or B)
Forced entry alarm (from Reader A or B)
Door held open alarm (from Reader A or B)
Door not open (from Reader A or B)
Input is active (from Inputs 1 to 8)
Unlock mode is on (from Reader A or B)
Unlock mode is off (from Reader A or B)
High security is on (from Reader A or B)
High security is off (from Reader A or B)
Turn ON general output
Turn OFF general output
Turn ON high security
Turn OFF high security
