The card access system integrates with the TX3 Telephone Access system by
utilizing a common network for both telephone access and card access systems.
A PC provides configuration and on-line monitoring of the card access and the
telephone access status. Once the system is configured, the PC is not required.
1.3 Configurable Features
The system is configured by connecting the inputs and outputs to device access
points, and using the configurator software to establish the correlations between
these inputs and outputs.
Additional physical configuration is required using the dip switches and jumpers
on the controller. DIP switches set the card access controller network address.
Jumper settings set the controller for firmware updates, last device on network
and the supply voltage.
1.3.1 PC Configurator Software
The Configurator Software TX3-MSW is a combined telephone access and card
access configurator that uses a common database. Once the controller is installed
the system applies its default values. Use the configurator software to fully
configure the system. See the following documentation:
•
•
1.4 Installer Responsibilities
The installation and setup must be done by a qualified technician. The technician
is responsible for installing all of the system components, connecting all of the
input and output wiring for the appropriate door entry systems, and ensuring that
the wiring adheres to the requirements of the system for proper operation using
the configurator software.
1.4.1 PC Requirements
The following are the PC requirements:
•
•
Version 1.00.3 TX3-CX Card Access System Installation and Operation Manual
Copyright 2009
LT-995 Configuration and Administration Guide
LT-973 TX3 Software Guide
Windows based configurator
Should support Windows XP or later
