JW4 JW3
JW2
JW6
Figure 18.
2.7

Setting Jumpers

There are six pre-set jumpers on the controller board as follows (refer to
Figure 18):
JW1. JW1 is used for updating firmware and by default is always closed (short).
Version 1.00.3 TX3-CX Card Access System Installation and Operation Manual
Copyright 2009
Card Access Controller
Address DIP Switches
SW2
SW2
JW5
JW1
Location of Jumpers JW1 to JW5 and Switches SW1 and SW2
Installation and Setup
ON
OFF
SW1
ON Card Access Controller
OFF
Power ON / OFF Switch
SW1
31 (56)
