2.1
Installing the Controller and Components
The card reader controller is surface mounted with four screws as shown in
Figure 3.
Install the following components as required:
•
•
•
The back cover is 12 inches wide by 14 inches long. The top two mounting holes
are 10 inches apart.
Thermal Kit
Figure 3.
To mount the card reader
1.
2.
16 (56)
Thermal kit TH-102 (optional)
Tamper switch (optional)
Modem TX3-MDM (optional) see Figure 5
12"
10"
Controller Back Cover Dimensions and Optional Component
Location
Using the controller back cover as a template mark the top two mounting
hole locations 10" apart as shown in Figure 3.
Place the screws halfway into the wall in the position shown using a
suitable screw.
TX3-CX Card Access System Installation and Operation Manual
Copyright 2009
Installation and Setup
Tamper Switch
12.4"
14"
Ground Wire with
#8 Screw Terminal -
Wire earth ground
to this point.
Version 1.00.3
