Card Reader A. Connections required for card reader A (starting from the far
bottom left side) are Beeper, Red LED, Green LED, PWR(+), COM(-), Data 0,
Data 1 and COM (-).
Card Reader B. Card reader B follows the same terminal connections, located
to the right of the card reader A terminals.
Note:
2.5.3

Card Reader Status LEDs

There are three status LEDs on the card reader:
Green LED. Illuminates steady green when door is unlocked.
Red LED. Illuminates steady red when door is locked.
Orange LED. Illuminates steady orange when any card is used for the first time.
Normal illumination returns upon subsequent use. (on some models only)
2.5.4

Card Reader Beeper

The beeper indicates specific events at different beep rates as follows:
Access Granted. Two short beeps.
Access Denied. One short beep and one long beep.
Mode of Operation Changed. Three short beeps indicate a change in the on or
off state for the high security or the unlock mode.
Alarm. Continuous short beeps.
2.6

Setting DIP Switches SW2

DIP switches set the card access controller address. Valid addresses are 1 to 31.
DIP switches 1 to 5 are used for binary addressing with DIP switch 1 being the
least significant bit. DIP switch SW2 is found at the top central portion of the card
access controller board, see Figure 5.
Note:
Version 1.00.3 TX3-CX Card Access System Installation and Operation Manual
Copyright 2009
When using card readers with a single LED control connect the
control wire to the green LED terminal.
DIP switches 6, 7 and 8 are not used and should remain at the factory
set values.
