Chapter 2: Jumpers and Connectors

Jumpers and DIP Switch Settings

AT/ATX Power Type Select

Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: JP5
1 3
Pin Settings
1-2 On AT
2-3 On ATX
Pin Definition
1 ATMODE
2 MODE_SEL
3 ATXMODE
Copyright © 2015 NEXCOM International Co., Ltd. All Rights Reserved.

LCD Power Select

Connector type: 1x3 3-pin header, 2.54mm pitch
Connector location: JP2
1 3
Pin Settings
1-2 On VCC3
2-3 On VCC5
1-2 On: default
Pin Definition
1 VCC3
2 VCCLCDIN
3 VCC5
37
