Network Interface Operation
The status lights and status sheet can provide you with important
information about the operation and configuration of the network
interface.
Status sheet button
USB upstream connector
USB downstream connector
DC-IN connector
Security lock
1. NETWORK light
2. DATA light
3. USB light
4. Status sheet button
5. USB upstream connector
6. USB downstream connector
7. DC-IN connector
8. Security lock
Back panel
Front panel
NETWORK light
DATA light
USB light
11
