Table 48 provides the WPIM-DI drop and insert interface cable pin assignments.

WPIM-HDSL

This section provides connector specifications for the WPIM-HDSL interface cables.
provides pin assignments for the RJ-45 network interface connector.
Table 49 WPIM-HDSL Network Interface Cable Pin Assignments
Table 48 WPIM-DI Drop and Insert
Pin Signal
1 Transmit Ring
2 Transmit Tip
3 AC Coupled Ground
4 Receive Ring
5 Receive Tip
6 AC Coupled Ground
7 AC Coupled Ground
8 AC Coupled Ground
Pin Signal
1 HDSL Loop 1 (Ring1)
2 HDSL Loop 1 (Tip1)
3 Not Used
4 HDSL Loop 2 (Ring2)
5 HDSL Loop 2 (Tip2)
6 Not Used
7 Not Used
8 Chassis Ground
WPIM Cable Specifications
CSX200 Family User's Guide 227
Table 49
