The following definitions explain each of the Flash Download screen fields.
Download Method —
firmware image to the CSX200.
• Reboot After Download —
chosen. Selecting YES forces the CSX200 to reboot and use the new firmware image
immediately. Selecting NO allows the CSX200 to continue using the existing firmware image
without interrupting network operation.
• Commit to Flash —
Selecting YES allows the CSX200 to continue using the existing firmware image without
interrupting network operation and selecting NO allows the CSX200 to reboot and use the new
firmware image immediately.
• TFTP Gateway Server IP —
is chosen. Use this field to enter the IP address of the TFTP Gateway Server.
Last Image Server IP —
image to the CSX200.
Last Image File Name —
CSX200.
Download Server IP —
to download the firmware image.
Download File Name —
download to the CSX200.

Selecting a Flash Download Method

1. Use the arrow keys to highlight the Download Method field.
2. Press the SPACEBAR or BACKSPACE to select a flash download method.
• If you select RUNTIME, the Reboot After Download field displays.
• If you select BOOTPROM, the Commit to Flash field and the TFTP Gateway Server IP
field display.
Use this field to select the method you wish to use to download the
This field displays when the RUNTIME Download Method is
This field displays when the BOOTPROM Download Method is chosen.
This field displays when the BOOTPROM Download Method
Displays the IP address of the last server used to download a firmware
Displays the file name of the last firmware image downloaded to the
Use this field to type in the IP address of the server from which you wish
Use this field to type in the file name of the firmware image you wish to
