WAN Configuration Using Local Management
7.
Use the arrow keys to highlight T1 Network Loopback. Press the SPACEBAR to select None,
then pressing ENTER.
8.
Use the arrow keys to highlight the SAVE command, then press ENTER. The message "SAVE
DONE!" displays and Local Management saves the changes to memory.
9.
Access the WAN Interface Configuration screen by using the arrow keys to highlight the WAN
Int Config option, then press ENTER.
Interface Configuration
This screen is accessed through the WAN Physical Configuration screen. Refer to
proceed with the following steps to configure the WAN Interface through Local Management.
1.
Set the WAN connection Interface Number by typing the same number into the Interface
Number field that was input into the Time Slots in the WAN Physical Configuration screen,
then press ENTER (refer to the NOTE on the previous page).
2.
Unless the user sets the Max Xmit Unit, the CSX200 automatically sets the Max Xmit Unit to
8191 (default) after the active protocol (PPP) is selected.
3.
If the T1 Line Coding is B8ZS on the previous screen, follow the steps below:
a.
Use the arrow keys to highlight Line Coding. Press the SPACEBAR to select None, then
press ENTER.
b.
Use the arrow keys to highlight Active Protocol. Press the SPACEBAR to select PPP, then
press ENTER.
c.
Use the arrow keys to highlight PPP Type. Press the SPACEBAR to select BNCP, then
press ENTER.
d.
Use the arrow keys to highlight CCP Enable. Press the SPACEBAR to select ON, if you
want data compression enabled or OFF, if you do not, then press ENTER.
4.
If the T1 Line Coding is AMI on the previous screen follow the steps below:
a.
Use the arrow keys to highlight Line Coding. Press the SPACEBAR to select INV-HDLC,
then press ENTER.
b.
Use the arrow keys to highlight Active Protocol. Press the SPACEBAR to select PPP, then
press ENTER.
c.
Use the arrow keys to highlight PPP Type. Press the SPACEBAR to select BNCP, then
press ENTER.
144
CSX200 Family User's Guide
Figure 67
and
