Page 1 CSX200 FAMILY USER’S GUIDE 2012-01...
Page 3: Fcc Notice
Notice Cabletron Systems reserves the right to make changes in speciﬁcations and other information contained in this document without prior notice. The reader should in all cases consult Cabletron Systems to determine whether any such changes have been made. The hardware, ﬁrmware, or software described in this manual is subject to change without notice. IN NO EVENT SHALL CABLETRON SYSTEMS BE LIABLE FOR ANY INCIDENTAL, INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT NOT LIMITED TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS MANUAL OR THE INFORMATION CONTAINED IN IT, EVEN IF CABLETRON SYSTEMS HAS BEEN...
Page 4: Vcci Notice
Notice VCCI Notice This is a Class A product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance may arise. When such trouble occurs, the user may be required to take corrective actions.
Page 5: United States Government Restricted Rights
Exclusion of Warranty and Disclaimer of Liability EXCLUSION OF WARRANTY. Except as may be specifically provided by Cabletron in writing, Cabletron makes no warranty, expressed or implied, concerning the Program (including its documentation and media). CABLETRON DISCLAIMS ALL WARRANTIES, OTHER THAN THOSE SUPPLIED TO YOU BY CABLETRON IN WRITING, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, WITH RESPECT TO THE PROGRAM, THE ACCOMPANYING WRITTEN MATERIALS, AND ANY ACCOMPANYING HARDWARE.
Page 6 Notice Application of Council Directive(s): Manufacturer’s Name: Manufacturer’s Address: European Representative Name: European Representative Address: Conformance to Directive(s)/Product Standards: Equipment Type/Environment: We the undersigned, hereby declare, under our sole responsibility, that the equipment packaged with this notice conforms to the above directives.
Page 7: Table Of Contents
CHAPTER 1 INTRODUCTION Related Documentation ... 1 How to Use This Guide ... 1 Document Conventions... 3 Getting Help ... 4 CHAPTER 2 ABOUT THE CSX200 CSX200 Hardware ... 5 WAN Connection ... 5 Ethernet LAN Connection... 7 Remote Management Capabilities ... 8 Optional Features ...
Page 8 Contents CHAPTER 3 10BASE-T LAN REQUIREMENTS Network Requirements... 21 10BASE-T Twisted Pair Network... 21 Port Descriptions... 22 10BASE-T LAN Configuration... 22 Connecting UTP Cables to Ports 1 Through 12 ... 23 CHAPTER 4 INSTALLATION Unpacking the CSX200... 25 Guidelines for Installations ... 25 Installing Interface Modules ...
Page 9 Bridging and Routing Configuration ... 64 Bridging and Routing Configuration Window ... 64 Bridging and Routing (WAN Frame Type) Configuration Window... 70 Routing Configuration Window ... 72 IP Routing Configuration ... 73 IPX Routing Configuration ... 73 Advanced Routing Configuration Window ... 76 QuickSET Pull-Down Menus...
Page 10 Selecting the Bridge Port Administrative Status ... 114 Selecting the Bridge Port Pair Administrative Status... 115 Router Setup Screen... 116 Router Setup Fields ... 116 IP Configuration Screen ... 117 IP Configuration Screen Fields ... 117 IP General Config Screen... 118 IP General Configuration Status Fields ...
Page 11 IPX Configuration Screen... 126 IPX Configuration Fields ... 126 IPX General Configuration Screen ... 127 IPX General Configuration Status Fields ... 127 IPX General Configuration Fields ... 128 IPX Routing over Frame Relay ... 131 Enabling the IPX SAP Routing Protocol on a Port ... 131 Enabling RIP on a Port ...
Page 12 Contents CHAPTER 8 MIB NAVIGATOR Chapter Organization ... 173 MIB Navigator Screen ... 174 Managing Device MIBs... 174 MIB Navigator Command Set Overview ... 175 Conventions for MIB Navigator Commands ... 176 Navigation Commands... 177 Other Commands... 187 Special Commands ... 199 CHAPTER 9 TROUBLESHOOTING Troubleshooting CSX200 Hardware ...
Page 13 APPENDIX A WPIM CABLE SPECIFICATIONS WPIM-T1 ... 213 WPIM-SY ... 215 EIA-449... 216 V.35 ... 217 EIA-232... 219 X.21 ... 220 EIA-530, EIA-530 ALT A, EIA-530 A, and EIA-530 A ALT A... 221 WPIM-DDS... 223 WPIM-E1... 224 WPIM-DI... 226 WPIM-HDSL... 227 APPENDIX B SPECIFICATIONS AND STANDARDS COMPLIANCE CSX200 Regulatory Compliance ...
Page 14 Contents xii CSX200 Family User’s Guide...
Page 15: Chapter 1 Introduction
Introduction Welcome to the Cabletron Systems CSX200 Family User’s Guide. This guide provides basic conﬁguration information, hardware speciﬁcations and troubleshooting tips for the CSX200 family of products that includes the CSX200, CSX201, CSX202, and CSX203. This guide also provides background information about 10BASE-T Ethernet Local Area Networks (LANs) and guidelines for routing and bridging over Wide Area Networks (WANs).
Page 16 Introduction Chapter 10BASE-T LAN Ethernet Local Area Network (LAN). Chapter 4, Installation, provides detailed installation instructions for attaching the CSX200 to a network. Chapter CSX200 Conﬁguration with CSX200 to a Wide Area Network (WAN) using Cabletron Systems QuickSET management utility. Chapter General Configuration Using Local conﬁguring the CSX200 through a TELNET connection.
Page 17: Document Conventions
Document Conventions The following conventions are used throughout this guide: Note symbol. Calls the reader’s attention to any item of information that may be of NOTE special importance. Tip symbol. Conveys helpful hints concerning procedures or actions. Caution symbol. Contains information essential to avoid damage to the equipment. CAUTION Warning symbol.
Page 18: Getting Help
Introduction Getting Help If you need additional support related to this device, or if you have any questions, comments, or suggestions concerning this manual, contact the Cabletron Systems Global Call Center: Phone Internet mail Login Password Modem setting For additional information about Cabletron Systems or our products, visit our World Wide Web site: http://www.cabletron.com/ For technical support, select Service and Support.
Page 19: About The Csx200
About the CSX200 The CSX200 (Figure 1) is an access device that provides Ethernet Local Area Network (LAN) connectivity via twelve RJ45 ports for the small ofﬁce and offers high-speed Wide Area Network (WAN) access to a remote site, such as the Internet or an enterprise network. The CSX200 supports IEEE 802.1d transparent bridging, IP and IPX routing, and Dynamic Host Conﬁguration Protocol (DHCP, Network Address Translation (NAT) routing between Ethernet LANs across a WAN.
Page 20 About the CSX200 • The WPIM-SY provides a synchronous serial connection of up to 2.048 Mbps to external communications equipment (e.g., a multiplexer or CSU/DSU). The WPIM-Sync uses a subminiature 26-pin connector that supports the electrical signal interfaces listed below. Appendix A, provides complete part number and cable pin assignment information on the following electrical signal interfaces:...
Page 21: Ethernet Lan Connection
Ethernet LAN Connection The CSX200 provides 10 Mbps Ethernet/IEEE 802.3 support through twelve (11 if Call Backup is enabled) 8-pin RJ45 10BASE-T ports on the front of the unit (see Repeater Functionality — 10BASE-T speciﬁcations, and provides the ﬂexibility to connect networks using IEEE 802.3, Ethernet Version 1 or Version 2 equipment.
Page 22: Remote Management Capabilities
About the CSX200 Remote Management Capabilities Manage the CSX200 remotely with any SNMP network management system including the following: • Cabletron Systems SPECTRUM for Open Systems • Cabletron Systems Remote SPECTRUM Portable Management Applications (SPMAs) • Cabletron Systems QuickSET • Cabletron Systems SPECTRUM Element Manager (SPEL) •...
Page 23: Ieee 802.3 Ethernet
IEEE 802.3 Ethernet The CSX200 provides a standard 802.3 Media Access Control (MAC) layer for Ethernet communications. All bridging and routing protocols are supported across the Ethernet link. WAN Protocols This device supports the following WAN protocols over the WAN port: •...
Page 24: Firmware Data Compression
About the CSX200 Firmware Data Compression The STAC Electronics Stacker LZS Compression algorithm provides a minimum of 2:1 ﬁrmware data compression for the CSX200 over PPP and Frame Relay. Firmware data compression is supported in software on each WAN interface for line speeds of up to 256 Kbps. per WPIM, which is equivalent to four DS0 channels.
Page 25: Point-To-Point Protocol (Ppp)
A private or “local” network is referred to as a sub network that is using private or NOTE “local” IP addresses. An “outside” network refers to a Wide Area Network (WAN) commonly known as an Internet, an Intranet is an “Internet” in use on a facility or campus where registered public IP addresses are required.
Page 26: Lqm
About the CSX200 In half-duplex operation, the authenticator device challenges the peer device by generating a CHAP challenge, and the challenge contains an MD5 algorithm with a random number that has your encrypted password and system name. The peer device then applies a one-way hash algorithm to the random number and returns this encrypted information along with the system name in the CHAP response.
Page 27: Bridging And Routing
Routing tables are also built dynamically (i.e., the location of remote stations, hosts and networks are updated through inter-router protocols). Routing helps to increase network capacity by localizing trafﬁc on LAN segments and broadcasts that would result from bridged trafﬁc.
Page 28 The CSX200 can operate as a bridge, a router, or both. The CSX200 Bridging and Routing — CSX200 operates as a router for network protocols that are supported when routing is enabled and operates as a bridge when bridging is enabled. When both bridging and routing are enabled, routing takes precedence over bridging;...
Page 29: Bridging And Routing Protocol Filtering
Bridging and Routing Protocol Filtering Filtering is used to allow efﬁcient usage of network resources and provide security for your network and hosts. The CSX200 supports IP Internet Firewall ﬁltering to prevent IP Internet Firewall — unauthorized access to your system and network resources from the Internet or a corporate Intranet.
Page 30: System Passwords
About the CSX200 System Passwords System passwords allow you to control access to the CSX200 by establishing three passwords. Each password provides varying levels of access to the CSX200. The default password for each access level is pre-set to public. If you do not wish to establish a password, press ENTER, the default password is automatically selected.
Page 31 SNMP MIB Support SNMP MIBs are databases of objects used for managing and determining the status and conﬁguration of an SNMP compliant device. The following SNMP MIBs are supported by the CSX200: • MIB IIRFC1213 • RMON MIBRFC1271 • DS1 and E1 MIBRFC1406(Digital Signal Level 1 [T1/E1 interface types]) •...
Page 32 About the CSX200 SNMP Trap Support SNMP Traps are notiﬁcations of network events sent by an SNMP compliant device to an SNMP management station. The following SNMP Traps are supported by the CSX200: IETF Standard Traps: • Warm Start Trap Type Code #1RFC1214 •...
Page 33 • IP Access Control Lists have been enabled on interface # • IP Access Control Lists have been disabled on interface # • IP has detected Port UP (WAN devices only) • IP has detected Port DOWN (WAN devices only) •...
Page 34: Software And Firmware Upgrades
About the CSX200 Software and Firmware Upgrades Software and Firmware upgrades can be performed remotely through the Windows-based QuickSET utility application. Refer to Chapter 5, for QuickSET instructions. QuickSET allows you to retrieve or upgrade the ﬁrmware, software, and conﬁguration ﬁles from its Firmware Upgrade menu by selecting the TFTP/BootP Services window to access a TFTP (Trivial File...
Page 35: Chapter 3 10Base-T Lan Requirements
10BASE-T LAN Requirements This chapter contains general networking guidelines for setting up a 10BASE-T Local Area Network using ports 1 through 12 on the CSX200. Review the requirements and speciﬁcations outlined in this chapter before attempting to install the CSX200. Network Requirements Take care in planning and preparing the cabling and connections for your network.
Page 36: Port Descriptions
10BASE-T LAN Requirements Multi-pair PVC 24 AWG telephone cable typically has an attenuation of Temperature — approximately 8–10 dB/100 m at 20 C (68 F). The attenuation of PVC insulated cable varies with temperature. At temperatures greater than 40 C (104 F), use plenum-rated cable to ensure that attenuation remains within speciﬁcation.
Page 37: Connecting Utp Cables To Ports 1 Through 12
Connecting UTP Cables to Ports 1 Through 12 Before connecting a segment to the CSX200, check each end of the segment to verify wire crossover. To establish a link, you must have an odd number of crossovers (preferably one) between 10BASE-T devices of the same type (i.e., from repeater to repeater or transceiver to transceiver).
Page 38 10BASE-T LAN Requirements Verify that the RJ45 connectors on the twisted pair segment have the proper pinouts (Figure 3) and check the cable for continuity. NOTE: RX+/RX– and TX+/TX– must share a common color pair. Figure 3 Cable Pinouts - (RJ45) Crossover Cable Check that the twisted pair connection meets the dB loss and cable specifications outlined 10BASE-T LAN If a link is not established, contact Cabletron Systems Technical Support.
Page 39: Chapter 4 Installation
Installation This chapter outlines the procedure for attaching the CSX200 to the network. Ensure that the network meets the guidelines and requirements outlined in Requirements, before installing the CSX200. Unpacking the CSX200 Unpack the CSX200 as follows: Remove the shipping material from the box and carefully remove the CSX200. Visually inspect the CSX200.
Page 40: Installing Interface Modules
Installation Installing Interface Modules Depending on your speciﬁc application, install Cableton Systems WAN Port Interface Modules (WPIMs) and the CSX-COMP/ENCR modules into the CSX200 before proceeding with the installation of your CSX200. Refer to the CSX200-COMP/ENCR Installation The WPIM, CSX200-COMP/ENCR, and the CSX200 are sensitive to static discharges.
Page 41 To remove the chassis cover, proceed as follows: Disconnect the CSX200 from the network as follows: Unplug the power cord from the rear of the CSX200 chassis. Before performing associated port numbers. This is recommended for ease of reinstallation. Disconnect all network cables attached to the CSX200. Use a flat-blade screwdriver to remove the cover screw attaching the cover to the CSX200 chassis (refer to Figure...
Page 42: Installing The Wan Port Interface Module (Wpim)
Installation Installing the WAN Port Interface Module (WPIM) Before performing installation procedures, ensure that the requirements outlined in the section, Tabletop and Shelf CAUTION To install a WPIM into the CSX200, refer to WPIM When removing an existing WPIM, make sure to pull the module straight out to avoid damaging the connector.
Page 43: Csx200-Comp/Encr Installation
Attach the disposable grounding strap to your wrist (refer to the instructions outlined on the disposable grounding strap package). Remove the CSX200 cover (refer to Remove the blank faceplate from the appropriate WAN slot. Orient the WPIM as shown in Carefully insert the WPIM connector into the WPIM connector pins on the CSX200.
Page 44 Installation Ensure that the CSX200-COMP/ENCR is aligned such that its connector pins NOTE correctly align with the D-Type connector on the chassis. Locate the D-Type connector and the standoffs on the chassis (refer to The D-Type connector pins of the CSX200-COMP/ENCR only fit one way onto the CSX200 D-Type connector.
Page 45: Installing The Csx200
Installing the CSX200 The CSX200 may be installed on a tabletop, shelf or in a 19-inch rack. Refer to Tabletop and Shelf Installations installation. CSX200 Rackmount Installation Tabletop and Shelf Installations The following two subsections provide guidelines for installation on a tabletop or shelf. Before performing tabletop or shelf installation procedures, ensure that the requirements outlined in the section, CAUTION...
Page 46: Csx200 Rackmount Installation
Installation CSX200 Rackmount Installation To attach the rackmount brackets, Cabletron Systems offers an accessory kit that includes rackmount brackets, mounting screws, and a strain-relief bracket for cable management. The accessory kit is not included with the CSX200, but is purchased separately from Cabletron Systems as part number CSX200-ACCY-KIT.
Page 47: Attaching The Strain-Relief Bracket
Attaching the Strain-Relief Bracket Attach the strain-relief bracket to the front of the CSX200 as follows: Locate the strain-relief bracket and four 8-32 x 3/8-inch, pan-head screws provided in the CSX200-ACCY-KIT. Using the four 8-32 x 3/8-inch, pan-head screws, attach the strain-relief bracket to the bottom of the CSX200 as shown in Figure 9 Attaching the Strain-Relief Bracket Rackmount...
Page 48: Attaching The Rackmount Brackets
Installation Attaching the Rackmount Brackets Refer to Figure 10 and proceed as follows to attach the rackmount brackets: Locate the four 8-32 x 1/4-inch screws and the two rackmount brackets in the CSX200-ACCY-KIT package. Using the four 8-32 x 1/4-inch screws, attach the rackmount brackets to the bottom of the CSX200 as shown in Figure Figure 10 Installing the Rackmount Brackets...
Page 49: Connecting The Csx200 To The Power Source
Continue the installation by connecting power as described in Power Source. Connecting the CSX200 to the Power Source The CSX200 has a universal power supply. This allows you to connect the CSX200 to NOTE power sources of 100–125 and 200–240 Vac, 50/60 Hz. To connect the CSX200 to the power source, perform the following steps: Plug the power cord into the back panel of the CSX200.
Page 50 Installation 36 CSX200 Family User’s Guide...
Page 51: Chapter 5 Csx200 Configuration With Quickset
CSX200 Conﬁguration with QuickSET This chapter provides step-by-step instructions for conﬁguring the CSX200 using QuickSET. Before conﬁguring the device, you must set up your computer based on the READ ME NOTE FIRST! documentation included with the product and installed the CSX200 based on the QuickSTART Guide located in the QuickSET CD case.
Page 52 CSX200 Configuration with QuickSET Figure 13 First Introductory Window Click on the Next>> button to continue the CSX200 conﬁguration, and the Second Introductory window shown in Figure 14 displays. CSX200 Family User’s Guide...
Page 53 CSX200 Configuration with QuickSET Figure 14 Second Introductory Window Click on the Next>> button and go to the Ethernet Conﬁguration section to continue the CSX200 conﬁguration. CSX200 Family User’s Guide...
Page 54: Ethernet Configuration
CSX200 Configuration with QuickSET Ethernet Conﬁguration This section explains how to conﬁgure the CSX200 Ethernet ﬁelds using QuickSET. Ethernet Conﬁguration Window The Ethernet conﬁguration window, shown in Figure 15, displays after clicking on the Next>> button in the Second Introductory window. The Local Ethernet IP address and Subnet Mask ﬁelds shown on the Ethernet Conﬁguration window are used for setting an IP address and Subnet Mask.
Page 55 CSX200 Configuration with QuickSET The Local Ethernet IP Address displays the IP address for the Local Ethernet IP Address — Ethernet interface. Place the cursor in this ﬁeld and type the preferred IP address in Dotted Decimal Notation (DDN) format. The IP address must be in this ﬁeld to continue. The Subnet Mask takes the same form as an IP address;...
Page 56 CSX200 Configuration with QuickSET The System Passwords window shown in Figure 17 displays System Passwords Window — after clicking on the Passwords... button in the Ethernet conﬁguration window previously shown Figure 15. The system passwords used by QuickSET are the same as the Community Names of the device that are used in Local Management through a Telnet application.
Page 57 The following deﬁnitions explain the ﬁelds in the System Passwords window shown in This access level allows reading of device parameters not including Read Only Access — system passwords. Place the cursor in this ﬁeld and type the new system password. Retype the system password in the Conﬁrm Password ﬁeld below the Read Only Access ﬁeld.
Page 58: Wide Area Configuration
CSX200 Configuration with QuickSET Wide Area Conﬁguration When conﬁguring the WAN with QuickSET , the Wide Area conﬁguration window that NOTE displays corresponds to the speciﬁc WPIM that is installed into the CSX200. Refer to the appropriate section listed below to conﬁgure your Wide Area interface on the CSX200: Wide Area T1 Configuration Window Wide Area E1 Configuration Window...
Page 59: Wide Area T1 Configuration Window
Wide Area T1 Conﬁguration Window The Wide Area T1 conﬁguration window shown in Next>> button in the Ethernet configuration window. Figure 18 Wide Area T1 Conﬁguration Window This section explains how to conﬁgure the CSX200 Wide Area T1 interface using QuickSET. The service provider (i.e., AT&T, Sprint, MCI, NYNEX, etc.) determines the settings for NOTE the following ﬁelds.
Page 60 CSX200 Configuration with QuickSET The line conﬁguration information shown in The CSX200 factory default settings are in bold. Conﬁguration Information Required by User T1 Frame Type T1 Line BuildOut T1 Line Coding T1 Loop-Back T1 Transmit Clock Source Time Slots (for Fractional T1) The following deﬁnitions explain the ﬁelds in the Wide Area T1 conﬁguration window.
Page 61 CSX200 Configuration with QuickSET Displays the T1 Transmit Clock Source. The choices for this ﬁeld T1 Transmit Clock Source — are Loop-Timing (Extracted Line Data) and Local-Timing (Internal Clock). The default setting for this ﬁeld is Loop-Timing. Displays the active protocol for the Wide Area T1 interface. The selections for this Protocol —...
Page 62: Wide Area E1 Configuration Window
CSX200 Configuration with QuickSET Wide Area E1 Conﬁguration Window The Wide Area (E1) conﬁguration window shown in Next>> button in the Ethernet configuration window. This section explains how to conﬁgure the CSX200 E1 WAN interface using QuickSET. The service provider determines the settings for the following ﬁelds. Consult the NOTE service provider for the correct settings.
Page 63 The line conﬁguration information shown in The CSX200 factory default settings are in bold type. Conﬁguration Information Required by User E1 Frame Type E1 Line Coding E1 Loop-Back E1 Transmit Clock Source Time Slots (for Fractional E1) The following deﬁnitions explain the ﬁelds in the E1 WAN conﬁguration window. Displays the E1 frame type.
Page 64: Wide Area Di Configuration Window
CSX200 Configuration with QuickSET Once the E1 WAN conﬁguration is complete, click on the Next>> button and go to the Wide Area Frame Relay Time Slot Configuration Window Wide Area PPP Time Slot Configuration Window section, depending on which protocol you are using. Wide Area DI Conﬁguration Window The Wide Area (DI) conﬁguration window shown in Figure 20...
Page 65 The service provider (i.e., AT&T, Sprint, MCI, etc.) determines the settings for the NOTE following ﬁelds. Consult the service provider for the correct settings. The line conﬁguration information shown in The CSX200 factory default settings are in bold. Conﬁguration Information Required by User T1 Frame Type T1 Line BuildOut...
Page 66 CSX200 Configuration with QuickSET Displays the signal level for the physical DI line. Set this to 0 dB unless the T1 Line BuildOut — service provider recommends another setting. The default setting for this ﬁeld is 0 dB. Click on the appropriate radio button for the following levels: •...
Page 67: Wide Area Synchronous Configuration Window
Wide Area Synchronous Conﬁguration Window The Wide Area Synchronous conﬁguration window shown in the Next>> button in the Ethernet conﬁguration window. This section explains how to conﬁgure the CSX200 Wide Area Synchronous interface using QuickSET. Figure 21 Wide Area Synchronous Conﬁguration Window The service provider (i.e., AT&T, Sprint, MCI, NYNEX, etc.) determines the settings for NOTE many of the following ﬁelds.
Page 68 CSX200 Configuration with QuickSET The line conﬁguration information shown in CSX200 factory default settings are in bold. Conﬁguration Information Required by User Sync Port Type Sync Flow Control Sync Clock Speed The following deﬁnitions explain the ﬁelds in the Synchronous WAN conﬁguration window. Displays the Synchronous port electrical interface type.
Page 69 CSX200 Configuration with QuickSET Displays your conﬁgured receive clock speed. The default setting for this Sync Clock Speed — ﬁeld is 64000 bits per second. The information necessary for you to set this ﬁeld is normally determined by the service provider. Select the down arrow button to make your selection from the list of clock speeds using the information provided by your service provider (if it is not listed, type the value in).
Page 70: Wide Area Dds Configuration Window
CSX200 Configuration with QuickSET Wide Area DDS Conﬁguration Window The Wide Area DDS conﬁguration window shown in Next>> button in the Ethernet configuration window. This section explains how to conﬁgure the CSX200 Wide Area DDS interface using QuickSET. Figure 22 Wide Area DDS Conﬁguration Window The service provider (i.e., AT&T, Sprint, MCI, NYNEX, etc.) determines the settings for NOTE Table 7...
Page 71 Table 7 shows the line conﬁguration information determined by your service provider. The CSX200 factory default settings are in bold. Conﬁguration Information Required by User DDS Line Mode DDS Clock Source DDS Loop Back This section describes the ﬁelds in the Wide Area DDS conﬁguration window. Displays the DDS Line Mode.
Page 72: Wide Area Hdsl Configuration Window
CSX200 Configuration with QuickSET Wide Area HDSL Conﬁguration Window The Wide Area HDSL conﬁguration window shown in Next>> button in the Ethernet configuration window. This section explains how to conﬁgure the CSX200 Wide Area HDSL interface using QuickSET. Figure 23 Wide Area HDSL Conﬁguration Window The wiring provider (i.e., Internet Service Provider (ISP) contractor, etc.) determines NOTE the settings for...
Page 73 Table 8 shows the line conﬁguration information normally determined by your wiring provider. The CSX200 factory default setting is in bold. Conﬁguration Information Required by User HDSL Transmit Clock Source This section describes the ﬁelds in the Wide Area HDSL conﬁguration window. HDSL Transmit Clock Source —...
Page 74: Wide Area Frame Relay Time Slot Configuration Window
CSX200 Configuration with QuickSET Wide Area Frame Relay Time Slot Conﬁguration Window The Wide Area Frame Relay Time Slot conﬁguration window shown in Figure 24 displays when you click on the Next>> button in the Wide Area T1, E1, or DI conﬁguration windows when Frame Relay is chosen as the WAN Protocol.
Page 75: Wide Area Ppp Time Slot Configuration Window
CSX200 Configuration with QuickSET Once the Wide Area Frame Relay Time Slot conﬁguration is complete, click on the Next>> button and go to the Bridging and Routing Configuration section. Wide Area PPP Time Slot Conﬁguration Window The Wide Area PPP Time Slot conﬁguration window shown in Figure 25 displays when you click on the Next>>...
Page 76 CSX200 Configuration with QuickSET The following section deﬁnes the Time Slots ﬁeld in the Wide Area PPP Time Slot conﬁguration window. A full line consists of 24 Time Slots (T1 and DI) or 31 Time Slots (E1) that are Time Slots — each capable of up to 64 Kbps throughput.
Page 77: Wide Area Hdsl Time Slot Configuration Window
CSX200 Configuration with QuickSET Wide Area HDSL Time Slot Conﬁguration Window The Wide Area HDSL Time Slot conﬁguration window shown in Figure 26 displays when you click on the Next>> button in the Wide Area HDSL conﬁguration window. Figure 26 Wide Area HDSL Time Slot Conﬁguration Window The following section deﬁnes the Time Slots in the Wide Area HDSL Time Slot conﬁguration window.
Page 78: Bridging And Routing Configuration
CSX200 Configuration with QuickSET Once the Wide Area HDSL Time Slot conﬁguration is complete, click on the Next>> button, and go to the Bridging and Routing Configuration window. Bridging and Routing Conﬁguration Once all the necessary network information is collected for the WAN, the CSX200 can be conﬁgured for bridging and/or routing using QuickSET.
Page 79 This section describes the ﬁelds in the ﬁrst Bridging and Routing conﬁguration window. This ﬁeld allows you to specify whether or not the CSX200 bridges trafﬁc. MAC Bridging — Click on the check box to turn MAC Bridging on. Spanning Tree Protocol — you to conﬁgure the CSX200 to use the Spanning Tree Protocol, which lets the remote device check for bridging loops, and other sites that use the Spanning Tree Protocol.
Page 80 CSX200 Configuration with QuickSET When an IP Access Control List (ACL) is enabled on a router port, each packet forwarded out this port is ﬁrst checked against the ACL. If the address(es) of a packet match the address(es) in the ﬁrst ﬁlter in the list, the packet is permitted or denied as speciﬁed by that ﬁlter.
Page 81 The following deﬁnitions explain the ﬁelds in the Firewall conﬁguration window. The Add Firewall button clears the ﬁelds in the Firewall conﬁguration window, NOTE allowing you to type in the ﬁelds as necessary. The Apply Changes button adds the newly entered ﬁlter to the Access Control List. ACL (Access Control List) —...
Page 82 CSX200 Configuration with QuickSET Use this pull-down list to select the upper layer protocol that you want to apply to the Protocol — access control ﬁlter. Each access control ﬁlter can apply to trafﬁc for all protocols included in the TCP/IP suite, or just to trafﬁc for a single protocol.
Page 83 UDP Service Domain Name Server TACACS-Database Service Bootstrap Protocol Server When you have ﬁnished making changes, click on the Apply Changes button. Once the Firewall conﬁguration is complete, click on the OK button to return to the Bridging and Routing conﬁguration window.
Page 84: Bridging And Routing (Wan Frame Type) Configuration Window
The Bridging and Routing (WAN Frame Type) window displays ﬁelds for each interface number and its associated WAN Frame Type. Select the WAN Native frame type for router to router communication. Select the Encapsulated Ethernet or Encapsulated Ethernet SNAP frame types for router-to-bridge, or bridge-to-bridge communication.
Page 85 CSX200 Configuration with QuickSET The WAN Frame Type window shown in Figure 30 allows you to select one of three frame types to be used over the WAN for each interface: Native WAN, Encapsulated Ethernet, and Encapsulated Ethernet SNAP. Select the WAN Frame Type that you wish to enable by clicking the appropriate radio button.
Page 86: Routing Configuration Window
CSX200 Configuration with QuickSET Routing Conﬁguration Window The (IP/IPX) Routing conﬁguration window shown in Figure 31 displays after clicking on the Next>> button in the second Bridging and Routing (WAN Frame Type) configuration window. Figure 31 Routing Conﬁguration Window This section describes the ﬁelds in the (IP/IPX) Routing conﬁguration window. Refer to the section IP Routing Configuration to conﬁgure the CSX200 for IP routing.
Page 87: Ip Routing Configuration
Displays the Subnet Mask assigned to the interface number. Subnet Mask — The Next Hop is the IP address of the IP port of the next router (in the direction of Next Hop — the subnet that you are deﬁning).
Page 88 Interface Number and Data Link Connection Identiﬁer (DLCI). The DLCI and Interface Number deﬁne the switched connection to the Telco central ofﬁce. Enter the remote WAN MAC address and the remote Router’s WAN Network number. Figure 32 Host Map Window This section describes the ﬁelds in the IP Advanced conﬁguration window.
Page 89 CSX200 Configuration with QuickSET Displays the Data Link Connection Identiﬁer. Use this ﬁeld to enter the DLCI, which is a DLCI — four-digit decimal number corresponding to the WAN virtual circuit connection to the Telco central ofﬁce. Displays the active IPX network number of the WAN connection. Use this WAN Network # —...
Page 90: Advanced Routing Configuration Window
CSX200 Configuration with QuickSET Advanced Routing Conﬁguration Window The Advanced Routing conﬁguration window shown in Figure 33 displays after you click on the Advanced button in the (IP/IPX) Routing configuration window. Use this window to enable RIP routing, conﬁgure a Dynamic Host Conﬁguration Protocol (DHCP) server on the CSX200, set an IP address for a remote DHCP server, or set up Network Address Translation.
Page 91 CSX200 Configuration with QuickSET Advanced IP Routing Settings This section describes the ﬁelds for the Advanced IP Routing Settings of the Advanced Routing conﬁguration window. Displays the active interface number. Interface # — Set this value only if you are going to use numbered mode. In Local WAN IP Address —...
Page 92 CSX200 Configuration with QuickSET DHCP Settings Conﬁguration Window The DHCP Settings conﬁguration window shown in Figure 35 displays after clicking on the DHCP Server... button in the Advanced Routing configuration window. The DHCP Settings conﬁguration window is used to conﬁgure the DHCP settings for the CSX200. Figure 35 DHCP Settings Conﬁguration Window The following deﬁnitions explain the ﬁelds in the DHCP Settings conﬁguration window: Check this box to allow the CSX200 to act as a DHCP server.
Page 93 The subnet mask for the default gateway (automatically set). Subnet Mask — Used to designate the amount of time the IP addresses in the pool can be used Lease Timeout — before they become invalid. Click on the pull-down menu to view a list of available leased timeout intervals.
Page 94 CSX200 Configuration with QuickSET NAT Settings Conﬁguration Window The Network Address Translation (NAT) Settings conﬁguration window shown in Figure 36 displays after clicking on the NAT Settings... button in the Advanced Routing conﬁguration window. The NAT Settings conﬁguration window is used to set up Network Address Translation on an Ethernet port.
Page 95 CSX200 Configuration with QuickSET Allows you to delete NAT proxy servers. Delete Proxy... — Figure 37 Add NAT Proxy Server Window Once your CSX200 Advanced Routing conﬁguration is complete, be sure to save any changes you make. Click on the Next>> button in the Advanced Routing conﬁguration window to return to the (IP/IPX) Routing conﬁguration window.
Page 96: Quickset Pull-Down Menus
CSX200 Configuration with QuickSET QuickSET Pull-Down Menus The File, Firmware Upgrade and Advanced Conﬁguration QuickSET pull-down menus allow you to store and restore conﬁgurations, initiate TFTP/BootP Services, and conﬁgure Compression and Congestion settings for your CSX200. File Menu This section describes the pull-down menu options from the File menu as shown in Figure Figure 38 File Menu CSX200 Family User’s Guide...
Page 97 CSX200 Configuration with QuickSET The Store Conﬁguration window shown in Figure 39 displays after Store Conﬁguration — clicking on the File pull-down menu and selecting Store Conﬁguration at the top of any QuickSET conﬁguration window. The Store Conﬁguration window stores the entire CSX200 conﬁguration to a ﬁle name and drive that you specify.
Page 98: Firmware Upgrade Menu
CSX200 Configuration with QuickSET Firmware Upgrade Menu This section describes the pull-down menu options from the Firmware Upgrade menu as shown in Figure Figure 41 Firmware Upgrade Menu CSX200 Family User’s Guide...
Page 99 CSX200 Configuration with QuickSET The TFTP/BootP Services window shown in Figure 42 displays after TFTP/BootP Services — clicking on the Firmware Upgrade pull-down menu and selecting TFTP/BootP Services at the top of any QuickSET conﬁguration window. The TFTP/BootP Services window allows you to access a TFTP (Trivial File Transfer Protocol) Server or BootP Server to download the latest version of CSX200 ﬁrmware.
Page 100: Advanced Configuration Menu
CSX200 Configuration with QuickSET The TFTP Server Address indicates the IP address of the PC TFTP Server IP Address — running this utility. The File Name ﬁeld indicates the location and name of the ﬁrmware image you are File Name — putting on your CSX200.
Page 101: Compression & Congestion Window
CSX200 Configuration with QuickSET Compression & Congestion Window The Compression & Congestion window shown in Figure 44 displays after you click on the Advanced Configuration pull-down menu and select Compression & Congestion at the top of any QuickSET conﬁguration window. Figure 44 Compression &...
Page 102 CSX200 Configuration with QuickSET The following deﬁne the ﬁelds in the Compression & Congestion window. Displays the available, pre-conﬁgured interface numbers. Interface — Displays the status of data compression for a speciﬁc interface. Options for this Compression — ﬁeld are either on (box shows a check mark) or off. The following deﬁnitions explain the ﬁelds for Frame Relay only: Displays the Committed Burst size, which is the maximum amount of data Committed Burst —...
Page 103: Chapter 6 General Configuration Using Local Management
General Conﬁguration Using Local Management This chapter explains how to access and manage the CSX200 and its attached segments through a TELNET connection. A general working knowledge of basic network operations and an understanding of management applications is helpful prior to using Cabletron Systems Local Management.
Page 104: Local Management Overview
General Configuration Using Local Management IPX Configuration Screen Local Management Overview Cabletron Systems Local Management is a management tool that allows a network manager to perform the following tasks: • Conﬁgure interconnected devices to form a network • Monitor the performance of the network •...
Page 105: Local Management Screen Elements
Local Management Screen Elements There are ﬁve basic ﬁeld elements shown in the Local Management screen in EVENT MESSAGE FIELD SAVED OK Local Management 01/23/96 System Date: Host IP Address 000.000.000.000 Subnet Mask 255.255.0.0 Phys Address 00-00-1D-16-26-F8 COM 1 Application: COM 2 Application: SAVE Figure 45 Sample Local Management Screen...
Page 106 General Configuration Using Local Management Table 11 describes the most common event messages. Event messages related to speciﬁc Local Management applications are described with those applications throughout this manual. Message SAVED OK NOT SAVED?--PRESS SAVE TO KEEP CHANGES NOTHING TO SAVE Display ﬁelds cannot be edited.
Page 107: Local Management Keyboard Conventions
Local Management Keyboard Conventions All key names appear in this manual as capital letters. For example, the Enter key displays as ENTER, the Escape key displays as ESC, and the Backspace key displays as BACKSPACE. Table 12 explains the keyboard conventions used in this manual as well as the key functions. Function These are selection keys that perform the same Local Management function.
Page 108: Navigating Within Local Management Screens
General Configuration Using Local Management Navigating Within Local Management Screens To navigate within a Local Management screen, use the arrow keys of the terminal or the workstation providing terminal emulation services. The Local Management screen cursor responds to the LEFT-ARROW, RIGHT-ARROW, UP-ARROW, and DOWN-ARROW keys. Each time you press an arrow key, the Local Management screen cursor moves to the next available ﬁeld in the direction of the arrow key.
Page 109: Hierarchy And Organization Of Local Management Screens
General Configuration Using Local Management shows the hierarchy of the Local Management screens. System Level SNMP Community Names SNMP Traps Flash Download Bridge Setup Router Setup WAN Setup IP General Config IP RIP IPX General Config IPX SAP IPX RIP...
Page 110: Exiting The Local Management Session
General Configuration Using Local Management Exiting the Local Management Session To exit from CSX200 Local Management, perform the following steps: Use the arrow keys to highlight the RETURN command at the bottom of the Local Management screen. Press ENTER. The previous screen in the Local Management hierarchy displays. Repeat steps 1 and 2 until the Main Menu screen displays.
Page 111: Accessing Local Management
Accessing Local Management This section explains how to access and use the Local Management menu screens. Menu screens provide a path to the setup screens and status screens. Using the Menu Screens Once you have accessed the CSX200 through a TELNET connection, the CSX200 Password screen, Figure 47, displays.
Page 112: Main Menu Screen
General Configuration Using Local Management • If you enter a valid password, the associated access level displays at the bottom of the screen and the Main Menu screen, • If no activity occurs for several minutes, the Password screen displays again indicating that you must reenter the password.
Page 113: Setup Menu Screen
Setup Menu. SETUP MENU SYSTEM LEVEL SNMP COMMUNITY NAMES SNMP TRAPS FLASH DOWNLOAD BRIDGE SETUP ROUTER SETUP WAN SETUP Figure 49 Setup Menu Screen — The SNMP Community Names screen allows you to change or Flash Image Version XX.XX.XX RETURN 2012_03...
Page 114 — The Bridge Setup screen allows you to select a Spanning Tree protocol and enable/disable switch ports. Router Setup — The Router Setup screen accesses two other screens that provide general IP conﬁguration and allow you to enable or disable the RIP (Routing Information Protocol) feature. WAN Setup –...
Page 115: System Level Screen
System Level Screen This section explains how to use the System Level screen to set the following parameters: • System Date • System Time • Host IP Address • Subnet Mask • Physical Address (MAC Address) • Default Gateway • Default Interface Figure 50 shows the CSX200 System Level screen.
Page 116 IP Forwarding Table. The Default Gateway is the IP address of the network device (gateway or router) used to forward SNMP traps to a management station. The default setting for this ﬁeld is NONE DEFINED. To set the Default Gateway, refer to Default Interface —...
Page 117: Setting The System Date
Setting the System Date The CSX200 is year 2000 compliant so that the System Date ﬁeld can be set beyond the year 1999. To set the system date, perform the following steps: Use the arrow keys to highlight the System Date field. Enter the date in a MM/DD/YYYY format.
Page 118: Setting The Host Ip Address
General Configuration Using Local Management Setting the Host IP Address To set the host IP address, perform the following steps: Use the arrow keys to highlight the Host IP Address field. Enter the IP address using Decimal Dotted Notation (DDN) format. For example: 134.141.25.17 Press ENTER.
Page 119: Setting The Subnet Mask
Setting the Subnet Mask Subnets are logical divisions of the network. To change the Subnet Mask from its default value, perform the following steps: Use the arrow keys to highlight the Subnet Mask field. Enter the Subnet Mask using Dotted Decimal Notation (DDN) format. Values for each decimal can be from 0 to 255.
Page 120: Snmp Community Names Screen
General Configuration Using Local Management SNMP Community Names Screen This section explains how to assign community names. Community names allow you to control Local Management access by establishing three passwords. Each password controls varying levels of access to CSX200 Local Management. CSX 200 Local Management SAVE Figure 51 SNMP Community Names Screen...
Page 121: Setting Snmp Community Names
This access level allows editing of some device conﬁguration parameters not read-write — including changing or viewing community names. This access level allows full management privileges. super-user — Setting SNMP Community Names To set a community name, perform the following steps: If you edit the super-user community name, be certain not to forget it.
Page 122: Snmp Traps Screen
General Configuration Using Local Management SNMP Traps Screen The SNMP Traps screen allows the user to conﬁgure the CSX200 to send traps to as many as eight remote management workstations. SNMP traps are messages about network events and device operational statistics. Access the SNMP Traps screen from the Setup Menu screen by using the arrow keys to highlight the SNMP Traps menu item and pressing ENTER.
Page 123: Setting The Snmp Trap Destination
Use this ﬁeld to enable the transmission of SNMP traps to the management Enable Traps — workstation. Setting the SNMP Trap Destination Each management workstation designated to receive SNMP traps from the CSX200 must have a valid IP address and community name. To set and enable SNMP trap destination, perform the following steps: Use the arrow keys to highlight the Trap Destination field you want to modify.
Page 124: Flash Download Screen
General Configuration Using Local Management Flash Download Screen The Flash Download screen allows you to download a ﬁrmware image from a TFTP server to the CSX200. Access the Flash Download screen from the Setup Menu screen by using the arrow keys to highlight the Flash Download menu item and pressing ENTER.
Page 125: Selecting A Flash Download Method
The following deﬁnitions explain each of the Flash Download screen ﬁelds. Use this ﬁeld to select the method you wish to use to download the Download Method — ﬁrmware image to the CSX200. • Reboot After Download — chosen. Selecting YES forces the CSX200 to reboot and use the new ﬁrmware image immediately.
Page 126 General Configuration Using Local Management RUNTIME Download If you select RUNTIME Download, perform the following steps: Use the arrow keys to highlight the Reboot After Download field. Press the SPACEBAR or BACKSPACE to select one of the following: • YES, if you want the CSX200 to reboot and use the new firmware image immediately. •...
Page 127: Bridge Setup Screen
Use the arrow keys to highlight the Download File Name field. Type the complete path and filename of the new image file to be downloaded. You must include all directories and subdirectories involved in accessing the file. Type the new entry over the previous entry.
Page 128: Bridge Setup Screen Fields
General Configuration Using Local Management Bridge Setup Screen Fields The following list describes each of the Bridge Setup screen ﬁelds: Spanning Tree Protocol — for this ﬁeld are IEEE 802.1, DEC, or NONE. Bridge Port Admin Status — Possible selections for this ﬁeld are ENABLED or DISABLED. Bridge Port Pair Admin Status —...
Page 129: Selecting The Bridge Port Pair Administrative Status
Press the SPACEBAR or BACKSPACE to select ENABLE or DISABLE. For example, the following bridge setup indicates that bridge port 01 is configured to bridge traffic to all ports: BRIDGE PORT ADMIN STATUS: PORT 01 - - > ALL PORTS [ENABLED] Use the arrow keys to highlight the SAVE command field.
Page 130: Router Setup Screen
General Configuration Using Local Management Router Setup Screen The Router Setup screen allows you to choose either IP or IPX routing for your CSX200. Access Router Setup, shown in SETUP menu item in the Setup Menu and pressing ENTER. The Router Setup screen displays.
Page 131: Ip Configuration Screen
The IP Conﬁguration screen enables you to access the IP General Conﬁg and IP RIP screens to conﬁgure the CSX200 for IP Routing and enable RIP on the CSX200. Access the IP Conﬁguration screen, shown in IP menu item on the Router Setup screen and pressing ENTER. The IP Configuration screen displays. CSX 200 Local Management IP Conﬁguration Screen Fields...
Page 132: Ip General Config Screen
The IP General Conﬁg screen allows you to conﬁgure the CSX200 for IP routing. Access the IP General Conﬁg screen by using the arrow keys to highlight the IP General Config option and pressing ENTER. The IP General Conﬁg screen shown in CSX200 Local Management Router Name: IP Version: XX.XX.XX IP Routing: ENABLED...
Page 133: Ip General Configuration Fields
Use this ﬁeld to toggle through a list of commonly used UDP port numbers. +REDIRECTOR- — UDP port numbers are associated with the relay agent functionality of the router. Use this ﬁeld to select the format of the frame in which IP packets are encapsulated Framing —...
Page 134 On each port, Frame Type speciﬁes the format of the frame in which IP packets are encapsulated for transmission. The Frame Type options available for each router port are dependent on the type of media supported by that router port.
Page 135 ENTER. The message “SAVED OK” displays. Enabling IP Forwarding on a Port By default, IP Forwarding is disabled on each router port. Your device does not begin forwarding IP data packets on any router port until you enable IP Forwarding on that port.
Page 136 General Configuration Using Local Management Use the arrow keys to highlight the SAVE command field at the bottom of the screen and then press ENTER. The message “SAVED OK” displays. Conﬁguring the UDP Broadcast Redirector To locate a server that can provide a particular network service, many IP hosts rely on the use of LAN broadcasts to send UDP service requests.
Page 137 LAN broadcasts are not forwarded across routers, ARP does not work beyond a host’s local network or subnetwork. One of the primary purposes of a router is to conﬁne LAN broadcast trafﬁc to each local network or subnetwork.
Page 138: Enabling The Rip Routing Protocol On A Port
IP Forwarding Table to forward IP packets. The ability to switch the RIP routing protocol on and off on a port-by-port basis provides great ﬂexibility. On the same device, some router ports can be running the RIP routing protocol while other router ports are not. If necessary, you can temporarily disable the RIP routing protocol on any port without affecting the rest of your conﬁguration.
Page 139 Use the ENTER key to toggle the entry to ENABLED. Use the arrow keys to highlight the SAVE command field at the bottom of the screen, and then press ENTER. The message “SAVED OK” displays. CSX 200 Local Management IP Address: xxx.xxx.xxx.xxx Port: +PORT- General Configuration Using Local Management...
Page 140: Ipx Configuration Screen
SAP screens to conﬁgure the CSX200 for IPX Routing and enable RIP routing or Source Advertisement Protocol (SAP) routing on the CSX200. Access the IPX Conﬁguration screen, shown in IPX menu item on the Router Setup screen and pressing ENTER. The IPX Configuration screen displays. CSX 200 Local Management IPX Conﬁguration Fields...
Page 141: Ipx General Configuration Screen
Access the IPX Genral Conﬁguration screen by using the arrow keys to highlight the IPX General Config menu item and pressing ENTER. The IPX General Configuration screen, shown in Figure 60, displays. CSX 200 Local Management Router Name: IPX Version: XX.XX.XX IPX Routing: ENABLED Port: 1 Description: Ctron CSX200 EnetPort MAC Address: 00-00-1D-22-46-B0 Oper Status: Enabled IPX Address: 0.0.0.0...
Page 142: Ipx General Configuration Fields
Routing Services allows you to choose the ports that you want to conﬁgure for IPX routing. To select a router port to conﬁgure for IPX routing, use the arrow keys to highlight the PORT option. You can type in the port number, or you can use the +PORT- option at the bottom of NOTE the screen to scroll through the list of the ports on your device.
Page 143 On each port, Frame Type speciﬁes the format of the frame in which IPX packets are encapsulated for transmission. The Frame Type options available for each router port are dependent on the type of media supported by that router port.
Page 144 ENTER. The message “SAVED OK” displays. Enabling IPX Forwarding on a Port By default, IPX Forwarding is disabled on each router port. Your device does not begin forwarding IPX data packets on any router port until you enable IPX Forwarding on that port.
Page 145: Ipx Routing Over Frame Relay
The Network is the IPX Network number associated with the Frame Relay network. Network — The Node is the MAC address of the remote router on the other end of the WAN link. Node — The Circuit ID is the DLCI identifying the virtual circuit connection to the Telco.
Page 146 General Configuration Using Local Management Each router running IPX SAP gathers this LAN based information from the locally connected network segments and adds it to its Service Advertisement Table. Each table contains the Novell Network Number and type of services available on all Novell servers known to the IPX SAP. IPX routing services uses this information to provide internetworked Netware clients with access to these services.
Page 147: Enabling Rip On A Port
IPX packets. The ability to switch RIP on and off on a port-by-port basis provides great ﬂexibility. On the same device, some router ports can be running RIP while other router ports are not. If necessary, you can temporarily disable RIP on any port without affecting the rest of your conﬁguration.
Page 148 General Configuration Using Local Management CSX 200 Local Management IPX Address: xxx.xxx.xxx.xxx Port: +PORT- CSX200 Family User’s Guide IPX RIP CONFIGURATION System Level RIP: Port Level RIP: SAVE Figure 63 IPX RIP Conﬁguration Screen Flash Image Version XX.XX.XX DISABLED DISABLED RETURN...
Page 149: Chapter 7 Wan Configuration Using Local Management
WAN Conﬁguration Using Local Management This chapter provides detailed instructions for conﬁguring your CSX200 Wide Area Network (WAN) interface. The WAN Interface must be conﬁgured and the device reset before conﬁguring router NOTE information into local management. Chapter Organization The CSX200 has the ﬂexibility to use a variety of WPIMs, with the exception of the NOTE WPIM-S/T.
Page 150: T1 Physical Configuration
WAN Configuration Using Local Management T1 Physical Conﬁguration To conﬁgure the WPIM-T1 for the CSX200, access the WAN Physical Conﬁguration screen for the WPIM-T1, shown in Figure item on Setup Menu screen (refer to Conﬁguration screen displays. CSX200 Local Management WPIM 1 Type: BRIM #:...
Page 151 Displays the interface mode (in this case the mode is always “Primary”). Mode — Displays the active status of the T1 port, Yes or No. Active — Interfaces — Displays the available interfaces (002 – 025). T1 Conﬁguration Fields The following line conﬁguration ﬁelds are displayed on the WAN Physical Conﬁguration screen shown in Figure The service provider (i.e., AT&T, Sprint, MCI, NYNEX, etc.) determines the settings for...
Page 152 WAN Configuration Using Local Management Network Loopback is a testing procedure that segments the line and T1 Network Loopback — allows the user to isolate faults. The selections for this ﬁeld toggle between None and Line-Loop. In Line-Loop all 24 channels are looped back to the T1 line. The CSX200 must be in Loop-Timing mode to use this option.
Page 153 Figure 66 shows a sample Time Slot conﬁguration for three sites. Of the 24 Time Slots, Site #1 uses 16 to communicate with Site #2 and the remaining 8 to communicate with Site #3. This conﬁguration varies tremendously depending on how the service provider maps out the T1 Time Slots.
Page 154: T1 Interface Configuration
WAN Configuration Using Local Management T1 Interface Conﬁguration This section describes the features of the WAN Interface Conﬁguration screen. Access the screen by using the arrow keys to highlight the WAN Int Conﬁg option at the bottom of the WAN Physical Conﬁguration screen, pressing ENTER.
Page 155 Displays the active OSI Layer protocol. This ﬁeld toggles between None, FR Active Protocol — (Frame Relay), or PPP (Point-to-Point). The default setting is None. If you select PPP, the following ﬁelds displays: PPP Type: Select BNCP from this field. CCP Enable: This field toggles between ON and OFF.
Page 156: Full T1 Configuration Using Ppp
WAN Configuration Using Local Management The quantity of application ports for a Frame Relay network is determined by the quantity of DLCIs (Data Link Connection Identiﬁers) assigned to that Interface. This is determined either manually or by the LMP (Link Management Protocol). Displays the Interface that is associated with the application port.
Page 157 Full T1 Physical Conﬁguration Begin conﬁguration by accessing the WAN Physical Conﬁguration screen through Local Management (Figure 64). Access the WAN Physical Conﬁguration screen from the Feature Selection screen that ﬁrst displays when you enter Local Management. Use the arrow keys to highlight the WAN Conﬁguration option, then press ENTER.
Page 158 WAN Configuration Using Local Management Use the arrow keys to highlight T1 Network Loopback. Press the SPACEBAR to select None, then pressing ENTER. Use the arrow keys to highlight the SAVE command, then press ENTER. The message “SAVE DONE!” displays and Local Management saves the changes to memory. Access the WAN Interface Configuration screen by using the arrow keys to highlight the WAN Int Config option, then press ENTER.
Page 159: Fractional T1 Configuration Using Ppp
Use the arrow keys to highlight CCP Enable. Press the SPACEBAR to select ON, if you want data compression enabled or OFF, if you do not, then press ENTER. Use the arrow keys to highlight the SAVE command, then press ENTER. The message “Save Done!”...
Page 160 WAN Configuration Using Local Management The line conﬁguration information shown in Conﬁguration Information Required by User Line Coding Frame Type Clock Source DS-0s (Time Slots) Fractional T1 Physical Conﬁguration Begin the physical conﬁguration by accessing the WAN Physical Conﬁguration screen through Local Management.
Page 161 Use the arrow keys to highlight T1 Tx Clock Source. Use the SPACEBAR to select Local (no clock source provided by telephone company) or Loop (clock source provided by telephone company), then press ENTER. If you are using a Local clock source, set only one end of the circuit for Local, the other end must be set for Loop.
Page 162: Frame Relay Configuration
WAN Configuration Using Local Management Use the arrow keys to highlight CCP Enable. Press the SPACEBAR to select ON, if you want data compression enabled or OFF, if you do not, then press ENTER. If the T1 Line Coding is AMI on the previous screen: Use the arrow keys to highlight Line Coding.
Page 163 The following information must be supplied to you by the service provider. type: ANSI T1.617 Annex D The line conﬁguration information shown in Conﬁguration Information Required by Customer Line Coding Frame Type Clock Source DS-0s (Time Slots) Frame Relay Physical Conﬁguration Begin physical conﬁguration by accessing the WAN Physical Conﬁguration screen through Local Management.
Page 164 WAN Configuration Using Local Management Use the arrow keys to highlight T1 Frame Type. Press the SPACEBAR to select ESF or D4, then press ENTER. Use the arrow keys to highlight T1 Tx Clock Source. Press the SPACEBAR to select Local (no clock source provided by telephone company) or Loop (clock source provided by telephone company), then press ENTER.
Page 165: Synchronous Physical Configuration
Upon saving this screen, the interface just conﬁgured is assigned to an application NOTE port (PT#) in the table on the right hand side of the screen once the device starts communicating with the service provider’s switch. The WAN conﬁguration is complete. Communication between the CSX200 and the service provider’s switch takes approximately 1 to 2 minutes to begin.
Page 166: Wan Physical Configuration Screen Fields
WAN Configuration Using Local Management WAN Physical Conﬁguration Screen Fields The following sections describe WAN Physical Conﬁguration screen ﬁelds and instructions for setting them. The WAN Physical Conﬁguration screen lets you conﬁgure the Physical Interface. The WAN Physical Conﬁguration screen displays the following information for each WPIM. WPIM 1 —...
Page 167: Synchronous Interface Configuration
Displays the clock source as External, Internal or Split. The default Sync Clock Source — setting is External. The Internal and Split settings are for Cabletron testing purposes only. Always set this ﬁeld to External. Cabletron testing purposes only. Displays 64000 (bps) upon start-up. Sync Tx Clock Speed —...
Page 168: Wan Interface Configuration Screen Fields
WAN Configuration Using Local Management WAN Interface Conﬁguration Screen Fields The following sections describe WAN Interface Conﬁguration screen ﬁelds. Displays active Interface Numbers. Use this ﬁeld to conﬁgure the Interface Interface Number — Numbers you assigned to the Time Slots on the WAN Physical Conﬁguration screen. User-conﬁgured ﬁeld that displays the maximum packet size that can be Max Xmit Unit —...
Page 169 If you select FR, the following ﬁelds display: FR LMP: This field displays NO LMI, Q.933-A or T1.617-D. Set this field to T1.617-D. The NO LMI setting is for specialized applications in which no Frame Relay Link Management is available or required. If NO LMI is selected, the following field is displayed: Circuit State: DLCI Address:...
Page 170: Ppp Configuration
WAN Configuration Using Local Management PPP Conﬁguration This section provides step-by-step instructions for connecting the CSX200 to a DDS (Digital Data System) circuit in a PPP environment. This example assumes the setup shown in two CSX200s. CSX200 SITE #1 Figure 73 WPIM-SY Interface Conﬁguration for PPP The line conﬁguration information shown in Conﬁguration Information Required by User...
Page 171 Set Force CTS and Force DSR to YES only if the CSU/DSU does not support these NOTE ﬂow control terms. Use the arrow keys to highlight the SAVE command. Then press ENTER. The message “SAVE DONE!” displays and Local Management saves the changes to memory. Access the WAN Interface Configuration screen by using the arrow keys to highlight the WAN Int Config option, then press ENTER.
Page 172: Frame Relay Configuration
WAN Configuration Using Local Management Frame Relay Conﬁguration This section provides instructions for connecting the CSX200 to a DDS (Digital Data System) circuit in a Frame Relay environment. This example assumes the setup shown in two CSX200s. CSX200 SITE #1 Figure 74 CSX200 Interface Conﬁguration for Frame Relay The line conﬁguration information shown in Conﬁguration Information...
Page 173 Set Force CTS and Force DSR to YES only if the CSU/DSU does not support these NOTE ﬂow control terms. Use the arrow keys to highlight the SAVE command. Then press ENTER. The message “SAVE DONE!” displays and Local Management saves the changes to memory. Access the WAN Interface Configuration screen by using the arrow keys to highlight the WAN Int Config option, then press ENTER.
Page 174: Dds Physical Configuration
WAN Configuration Using Local Management DDS Physical Conﬁguration To conﬁgure the WPIM-DDS for the CSX203 or CSX200, access the WAN Physical Conﬁguration screen for the WPIM-DDS, shown in highlight the WAN SETUP menu item on Setup Menu screen (refer to ENTER.
Page 175 WAN Configuration Using Local Management Displays the WPIM mode. The ﬁeld toggles between PRIMARY and SECONDARY. In Mode — a device such as the BRIM-W6 where two WPIMs are utilized, but only one can be active at a given time, the second WPIM installed or recognized defaults to Secondary. Displays the status of the WPIM, Yes (active) or No.
Page 176: Dds Interface Configuration
WAN Configuration Using Local Management DDS Interface Conﬁguration This section describes the features of the WAN Interface Conﬁguration screen. Access the screen by using the arrow keys to highlight the WAN INT CONFIG command ﬁeld at the bottom of the Physical Conﬁguration screen, then press ENTER.
Page 177: Wan Interface Configuration Screen Fields
WAN Interface Conﬁguration Screen Fields The following sections describe WAN Interface Conﬁguration screen ﬁelds: Displays active Interface Number. Use this ﬁeld to conﬁgure the Interface Interface Number — Number assigned to the CSX200 on the WAN Physical Conﬁguration screen. Max Xmit (Transmit) Unit — can be transmitted on the selected interface.
Page 178 WAN Configuration Using Local Management If you select FR, the following ﬁeld displays: FR LMP: This field displays NO LMI, Q.933-A or T1.617-D. Set this field to T1.617-D. The NO LMI setting is for specialized applications in which no Frame Relay Link Management is available or required.
Page 179: Dds Configuration
DDS Conﬁguration This section provides step-by-step instructions for connecting the CSX200 to a Digital Data Service circuit in a PPP or Frame Relay environment. This example assumes the setup shown in Figure 77 using two CSX200s. CSX200 SITE #1 Figure 77 WPIM-DDS Interface Conﬁguration for PPP The line conﬁguration information shown in Conﬁguration Information Required by User...
Page 180 WAN Configuration Using Local Management DDS Physical Conﬁguration The WAN Physical Conﬁguration screen is accessed from Local Management by using the arrow keys to highlight the WAN SETUP option on Setup Menu screen (see ENTER. The WAN Physical Conﬁguration screen shown in Use the arrow keys to highlight DDS Line Mode.
Page 181 If you selected FR, use the arrow keys to highlight FR LMP. Press the SPACEBAR to select T1.617-D, Q.933-A, or NO LMI, then press ENTER. • Use the arrow keys to highlight DLCI Address. This ﬁeld can be set to values from 0–1023.
Page 182: Hdsl Physical Configuration
WAN Configuration Using Local Management HDSL Physical Conﬁguration To conﬁgure the WPIM-HDSL for the CSX200, access the WAN Physical Conﬁguration screen for the WPIM-HDSL, shown in menu item on Setup Menu screen (refer to Conﬁguration screen displays. Local Management WPIM 1 Type: HDSL BRIM #: 1 Mode: [Primary]...
Page 183: Wan Physical Configuration Screen Fields
WAN Physical Conﬁguration Screen Fields The following list describes the WAN Physical Conﬁguration screen ﬁelds. Displays conﬁguration information for the WPIMs that are installed. WPIM # — Displays the WPIM type. Type — Displays the BRIM slot in which the WPIM resides. BRIM # —...
Page 184: Hdsl Interface Configuration
WAN Configuration Using Local Management HDSL Interface Conﬁguration To access the WAN Interface Conﬁguration screen shown in highlight the WAN INT CONFIG selection at the bottom of the WAN Physical Conﬁguration screen, then press ENTER. Local Management Interface Number: Max Xmit Unit: Line Coding: Active Protocol: PORTS:...
Page 185 Displays the active OSI Layer protocol. This ﬁeld displays None, FR (Frame Active Protocol — Relay), or PPP (Point-to-Point). The default setting is None. If you select PPP, the following ﬁeld appears: This field displays BNCP or LEX. PPP Type: Circuit State: Toggles between Active, Inactive and Invalid.
Page 186 WAN Configuration Using Local Management CSX200 Family User’s Guide...
Page 187: Chapter 8 Mib Navigator
MIB Navigator This chapter explains how to use the MIB Navigator utility. The MIB Navigator allows access to a command set from which you can conﬁgure and manage the CSX200. Chapter Organization The following list summarizes the organization of this chapter: MIB Navigator Screen –...
Page 188: Mib Navigator Screen
MIB Navigator MIB Navigator Screen Access the MIB Navigator screen from the Main Menu screen using Local Management (refer to Accessing Local Management MIB NAVIGATOR option, then press ENTER. The MIB Navigator screen shown in appears. Welcome to MIB Navigator MIBNav->...
Page 189: Mib Navigator Command Set Overview
The MIB Navigator views the MIB tree hierarchy as a directory. hierarchy. Each layer is numerically encoded, so that every branch group and leaf object in the MIB is identiﬁed by a corresponding number, known as an Object Identiﬁer (OID). This allows the MIB Navigator to navigate through the MIB and access the manageable leaf objects.
Page 190: Conventions For Mib Navigator Commands
MIB Navigator Other commands allow you to access and manage network devices Other Commands — connected to the device running the MIB Navigator. The commands are as follows: dhcp ping secondIP snmpnext Special Commands allow you to exit from the MIB Navigator. The Special Commands —...
Page 191: Navigation Commands
MIB Navigation Commands are listed in the format shown below: command: Syntax: This entry provides the format that the MIB Navigator command requires. It indicates where arguments, if any, must be speciﬁed. Description: This entry brieﬂy describes the command and its uses. Options: This entry lists any additional ﬁelds which may be added to the command and their format.
Page 192 MIB Navigator cd [path] or cd <option> Syntax: Description: The cd command allows you to change directories within a MIB subtree (branch). The path speciﬁed must be valid, or the MIB Navigator will not perform the cd operation. Options: .. Moves you one subtree above the current one. / Moves you to the root.
Page 193 help: help <command> Syntax: Description: The help command provides general help on how to use the MIB Navigator or how to use a particular MIB Navigator command. Options: A particular MIB Navigator command. Example: mib2: mib2 Syntax: Description: The mib2 command allows you to move directly to the MIB II subtree (1.3.6.1.2.1) without entering the entire path.
Page 194 MIB Navigator next: next [path] Syntax: Description: The next command enables you to determine the next leaf in the speciﬁed path within the managed device’s MIB. Options: Not Applicable Example: pwd: Syntax: Description: The pwd command displays the full pathname for the directory in which you are currently working.
Page 195 set: set <OID> <value> Syntax: Description: The set command enables you to set the value of a managed object. This command is valid only for leaf entries in the current MIB tree, or for managed objects in the MIB. If the leaf speciﬁed does not exist for the given path, MIB Navigator asks for a value.
Page 196 MIB Navigator Example: Syntax: su [community name] Description: The su command enables you to change your community name to allow for different access to the MIB. The community name that you enter allows you either read-only, read-write, or super-user access to that device’s MIBs, depending on the level of security access assigned the password through the SNMP Community Names screen.
Page 197 tree: tree Syntax: Description: The tree command provides a display of the entire MIB for the device. Leaves and associated values are displayed in columns. Options: Not Applicable Example: whoami: Syntax: whoami Description: The whoami command displays your community string and access privileges to the MIB.
Page 198 MIB Navigator grep: grep <option> string Syntax: Description: Allows a user to search the MIB tree for a speciﬁc character string. All leafs in the MIB tree are searched. -m: Displays on the terminal one screenful at a time. Options: -i: Ignores case when searching for string.
Page 199 dir: dir [- 1pdm] [PATH] Syntax: Description: Lists the contents of the directory sub-tree speciﬁed. If no [directory-path] is speciﬁed, the contents of the current directory are displayed. The display options are: -1: Displays the OID value along with the ASCII name of the leaf object. -p: Lists all the entries along with the path name of the leaf object.
Page 200 MIB Navigator ls [-1pdm] [PATH] Syntax: Description: Lists the contents of the directory sub-tree speciﬁed. If no [directory-path is speciﬁed, the contents of the current directory are displayed. The display options are: -1: Displays the OID value along with the ASCII name of the leaf object. -p: Lists all the entries along with the path name of the leaf object.
Page 201: Other Commands
Other Commands The Other commands listed in this section activate functions on the LM managed device or devices being accessed through MIB Navigation. arp: arp <options> Syntax: Description: The arp command provides access to the ARP (Address Resolution Protocol) cache, enabling you to view cache data, delete entries, or add a static route.
Page 202 MIB Navigator Example: defroute: Syntax: defroute [interface number] [IP address] Description: The defroute command allows you to set the default IP route to a managed device through the speciﬁed interface. Options: Not Applicable Example: CSX200 Family User’s Guide MIBNav-> arp -a # Interface Network Address # (SonicInt)
Page 203 dhcp: dhcp <options> Syntax: Description: The dhcp command provides a status of the Dynamic Host Conﬁguration Protocol feature. Allows the user to enable/disable DHCP globally and by interface, and to conﬁgure interfaces with server parameters. dhcp (with no options) Displays DHCP status information. Options: dhcp enable/disable.
Page 204 MIB Navigator Example: CSX200 Family User’s Guide MIBNav->dhcp DHCP Server Summary: Admin: Enabled Oper: Enabled Server Time: 458400 Discovers: 0, Offers: 0, Requests: 2, Errors: 0 Declines: 0, Releases: 0, Acks: 2, Naks: 0, Other Servers: 0 DHCP Interface Configuration: Admin Oper ServerIP...
Page 205 nat: nat <options> Syntax: Description: The nat command provides status relating to Network Address Translation. Allows the user to assign a private network to an interface, to deﬁne an interface to access the internet through, and to create a public IP address to be used on the internet.
Page 206 MIB Navigator netstat: netstat <option> Syntax: Description: The netstat command provides a display of general network statistics for the managed device. The netstat command must be used with one of the two display options. -i Displays status and capability information for each interface Options: -r Displays routing information for each interface Example:...
Page 207 snmpbranch: snmpbranch [IP address] [community name] [OID] Syntax: Description: The snmpbranch command enables you to query another SNMP device. The command provides a display of objects that match the speciﬁed OID. If no match is made, no object is displayed. Options: Not Applicable Example:...
Page 208 MIB Navigator snmpset: snmpset [IP address] [community name] Syntax: Description: The snmpset command enables you to set the value of an object in other SNMP devices. This command requires the appropriate community string and OID. When deﬁning a new leaf set, MIB Navigator asks for a value. The following lists possible value types: (i)nteger - number (c)ounter - number...
Page 209 snmptree: snmptree [IP address] [community name] Syntax: Description: The snmptree command provides a display of all objects in the device and their corresponding values. Options: Not Applicable Example: traceroute: traceroute [IP address] Syntax: Description: The traceroute command generates a TRACEROUTE request to a speciﬁed IP address and provides a display of all next-hop routers in the path to the device.
Page 210 MIB Navigator bridge: bridge <ENABLE/DISABLE> <IFNUM/ALL> Syntax: Description: Allows management of bridging upon one or more interfaces of the device. Bridging may be enabled or disabled at your request, either one at a time or all at once. Specifying a single interface number affects the bridging status of that interface, while specifying ALL affects every interface of the device.
Page 211 Example: ppp: Syntax: Description: Provides additional status relating to PPP and its Network Control Protocols. Options: Not Applicable reset: reset Syntax: Description: The reset command allows you to perform a soft reset of the device. The user is queried to conﬁrm the reset command to insure against unwanted resets.
Page 212 MIB Navigator route: route add <IPADDRESS> <IPADDRESS> <INTERFACENUM> Syntax: route add <IPADDRESS> <IPADDRESS> <INTERFACENUM> <METRIC> route delete <IPADDRESS> <IPADDRESS> <INTERFACENUM> Description: Allows you to add or delete static entries in the IP Forwarding Table for the device. The ﬁrst address is the destination. The second address is the next hop for the given interface.
Page 213: Special Commands
snmpnext: snmpnext [IPADDRESS] [COMMUNITY-STRING] [OBJECT-ID] Syntax: Description: The snmpnext command allows the user to query another device using SNMP. The next leaf of an object identiﬁer can be retrieved from that device by supplying an appropriate community string and the values of the object identiﬁer.
Page 214 MIB Navigator CSX200 Family User’s Guide...
Page 215: Chapter 9 Troubleshooting
Troubleshooting Use this chapter in conjunction with the LANVIEW status monitoring and diagnostic LEDs on the CSX200 to diagnose power failures, collisions, cable faults and link problems. the front panel LEDs. Table If you are having difﬁculty installing and conﬁguring the CSX200, take the following steps: •...
Page 216 Troubleshooting Receive (RCV) Link (LNK) Transmit (XMT) Receive (RCV) Link (LNK) Test CSX200 Family User’s Guide Table 21 CSX200 LAN LED States Color State Not receiving trafﬁc AMBER (ﬂashing) Receiving trafﬁc Link does not exist GREEN NORMAL, link exists Table 22 CSX200 WAN LED States Color State Not transmitting trafﬁc...
Page 217 Table 23 CSX200 WAN LED States for STS 1 WPIM Color T1, DI, and E1 AMBER SYNC GREEN HDSL GREEN Table 24 CSX200 WAN LED States for STS 2 WPIM Color T1, DI, and E1 AMBER SYNC GREEN HDSL GREEN State Normal or port disabled Red alarm...
Page 218: Troubleshooting Csx200 Hardware
Troubleshooting Troubleshooting CSX200 Hardware Power (PWR) LED is OFF • Check that the power connection is ﬁrmly attached to the back panel of the CSX200, and the other end to an active power source. Processor (CPU) LED is OFF If the CPU stays OFF for an extended amount of time, and the power (PWR) light remains on, the CPU is in an unknown state.
Page 219: Troubleshooting The Wan
Troubleshooting the WAN Link (LNK) LED is OFF The WAN interface is not conﬁgured for operation. • Use QuickSET or Local Management to make sure that the WAN interface is conﬁgured correctly. Link (LNK) LED is RED The WAN interface is conﬁgured, but there is no signal indicating that a valid connection is present on the WAN interface.
Page 220: Status 1 (Sts1) Led Is Red
Troubleshooting WPIM-SYNC Installed in CSX200 The port is operating normally. If it is not, and this LED is OFF the port may be disabled or RTS may be inactive. • Use QuickSET or Local Management to make sure that the WAN interface on the Local device is conﬁgured correctly.
Page 221: Status 1 (Sts1) Led Is Amber
WPIM-HDSL Installed in CSX200 WPIM-HDSL is conﬁgured for either Full or Fractional T1 and the WPIM is not able to establish synchronization on Loop 1 with the remote HDSL circuit. • Verify using QuickSET of Local Management that one of the WPIM-HDSL is involved in the connection is set to Master (Local) Timing and that the other one is set to Slave (Loop) Timing.
Page 222: Status 2 (Sts2) Led Is Off
Troubleshooting WPIM-HDSL is installed in CSX200 The Port is operating normally, Loop 1 has synchronized with the HDSL circuit at the remote end. Status 2 (STS2) LED is OFF WPIM-T1, WPIM-E1, WPIM-DI, or WPIM-DDS Installed in CSX200 The port is operating normally. If it is not, and this LED is OFF the port may be disabled. •...
Page 223: Status 2 (Sts2) Led Is Amber
• Verify the use of proper cabling for the HDSL connections. Category 3 or Category 5 Unshielded Twisted Pair copper wiring is required. One pair (2 wires) for Fractional T1, two pair (4 wires) for Full T1. The presence of bridged taps and multiple wire segments connected together to form the loop may reduce the maximum distance usable between the Remote and Local devices.
Page 224: Test (Tst) Led Is Amber (Blinking)
Check that your LAN cable is wired correctly and each end securely plugged in. • Make sure that an IP route exists between your local PC and the CSX200. The PC and CSX200 must be on the same IP subnetwork or the CSX200 must be reachable through a router on your LAN. •...
Page 225 • Check that TCP/IP Routing is set on and is enabled at the remote end. • Check that the IP address of the LAN beyond the remote router is correct, as well as the associated Subnet Mask. • If the remote router WAN IP address and Subnet Mask are required, check that they have been speciﬁed correctly.
Page 226 Troubleshooting CSX200 Family User’s Guide...
Page 227: Appendix Awpim Cable Specifications Wpim-T1
WPIM Cable Speciﬁcations For all WPIM cables, there is part number information for ordering a standard 20-foot NOTE cable or a speciﬁed length of cable. The number 20 followed by the part number denotes the standard 20-foot cable. The letter “L” denotes the speciﬁed length required in feet or meters.
Page 228: Csx200 Family User's Guide
WPIM Cable Specifications Table 27 provides RJ48 DTE pin assignments. Table 28 provides RJ48 network pin assignments. CSX200 Family User’s Guide Table 27 DTE Pin Assignments Signal Receive Ring Receive Tip Not Used Transmit Ring Transmit Tip Not Used Shield Ground Shield Ground Table 28 Network Pin Assignments Signal...
Page 229: Wpim-Sy
WPIM-SY This section provides the Cabletron Systems part number and connector speciﬁcations for the WPIM-SY interface cables. Table 29 provides the cable and interface types, electrical types, and part numbers for the WPIM-SY. Cable and Interface Type RS449 V.35 RS232 X.21 RS530 RS530 ALT A...
Page 230: Eia-449
WPIM Cable Specifications EIA-449 Table 30 shows the connector number, cable assembly description, and connector type. Connector Number Table 31 provides pin assignments for the EIA-449 interface cable. Table 31 EIA-449 Interface Cable Pin Assignment Connector 1 EIA-530A ALT A DIRECT MNEMONIC Transmit Data A...
Page 231: V.35
Table 31 EIA-449 Interface Cable Pin Assignment (Continued) Connector 1 EIA-530A ALT A DIRECT MNEMONIC Ring Indicator Test Mode DCE Ready DTE Ready Signal Common Signal Common V.35 Table 32 shows the connector number, cable assembly description, and connector type. Connector Number Table 33 provides pin assignments for the V.35 interface cable.
Page 232 WPIM Cable Specifications Table 33 V.35 Interface Cable Pin Assignment (Continued) Connector 1 EIA-530A ALT A DIRECT MNEMONIC Transmit Signal Transmit Signal Receive Signal Receive Signal Transmit Signal Transmit Signal Ring Indicator Test Mode DCE Ready DTE Ready Remote Loopback Local Loopback Signal Common Signal Common...
Page 233: Eia-232
EIA-232 Table 34 shows the connector number, cable assembly description, and connector type. Connector Number Table 35 provides pin assignments for the EIA-232 interface cable. Table 35 EIA-232 Interface Cable Pin Assignment Connector 1 EIA-530A ALT A DIRECT MNEMONIC Request to Send Transmit Signal Timing Receive Signal Timing Transmit Signal Timing...
Page 234: X.21
WPIM Cable Specifications X.21 Table 36 shows the connector number, cable assembly description, and connector type. Connector Number Table 37 provides pin assignments for the X.21 interface cable. Table 37 X.21 Interface Cable Pin Assignment Connector 1 EIA-530A ALT A DIRECT MNEMONIC Transmit Data A...
Page 235: Eia-530, Eia-530 Alt A, Eia-530 A, And Eia-530 A Alt A
EIA-530, EIA-530 ALT A, EIA-530 A, and EIA-530 A ALT A Table 38 shows the connector number, cable assembly description, and connector type for the EIA-530, EIA-530 ALT A, EIA-530A, and EIA-530A ALT A, interface cables. Table 38 EIA-530, EIA-530 ALT A, EIA-530A, and EIA-530A ALT A Interfaces Connector Number Table 39 provides the cable pin assignments for the EIA-530, EIA-530 ALT A, EIA-530A, and...
Page 236 WPIM Cable Specifications Table 39 EIA-530, EIA-530 ALT A, EIA-530A, and EIA-530A ALT A Interface Cable Pin Assignments Connector 1 EIA-530A ALT A DIRECT MNEMONIC Transmit Signal Timing A 15 Transmit Signal Timing B 12 Receive Signal Timing A 17 Receive Signal Timing B Transmit Signal Timing A 24 Transmit Signal Timing B 11...
Page 237: Wpim-Dds
WPIM-DDS This section provides Cabletron Systems part number and connector speciﬁcations for the WPIM-DDS interface cable. The WPIM-DDS has one RJ45 port for a direct connection to a single Digital Data Service (DDS) circuit. Table 40 provides cable and interface type, and part number information for the WPIM-DDS interface cable, and Table 41 cable.
Page 238: Wpim-E1
WPIM Cable Specifications WPIM-E1 This section provides the Cabletron Systems part number and connector speciﬁcations for the WPIM-E1 interface cable. Table 42 shows the WPIM-E1 connector number, cable and interface type, connector type and part number information. Connector Number Table 43 provides WPIM-E1 network interface cable pin assignments.
Page 239 Table 44 provides WPIM-E1 DTE interface cable pin assignments. Table 45 provides WPIM-E1 RJ45 network interface cable pin assignments. Table 44 DTE Interface Signal Receive Ring Receive Tip Shield Ground Transmit Ring Transmit Tip Shield Ground Not Used Not Used Table 45 Network Interface Signal Receive Ring...
Page 240: Wpim-Di
WPIM Cable Specifications WPIM-DI This section provides Cabletron Systems part number and connector speciﬁcations for the WPIM-DI interface cables. Table 46 shows the connector number, cable assembly description, cable and interface type, connector type and part number information for the WPIM-DI interface. Connector Cable Assembly Description Number...
Page 241: Wpim-Hdsl
Table 48 provides the WPIM-DI drop and insert interface cable pin assignments. WPIM-HDSL This section provides connector speciﬁcations for the WPIM-HDSL interface cables. provides pin assignments for the RJ-45 network interface connector. Table 49 WPIM-HDSL Network Interface Cable Pin Assignments Table 48 WPIM-DI Drop and Insert Signal Transmit Ring...
Page 242 WPIM Cable Specifications CSX200 Family User’s Guide...
Page 243 Speciﬁcations and Standards Compliance This chapter contains hardware speciﬁcations, and safety and compliance standards for the CSX200, and for the individual WPIMs that can be conﬁgured with this device. WAN Interface LAN Interface Other Interfaces Processor Width Height Depth Weight Power Supply Voltage Frequency...
Page 244: Specifications And Standards Compliance Csx200 Regulatory Compliance
Specifications and Standards Compliance CSX200 Regulatory Compliance This unit meets the safety requirements of UL 1950, CSA C22.2 No. 950 and Safety — EN 60950, IEC 950, and 73/23/EEC. Electromagnetic Compatibility (EMC) — 15, EN 55022, EN 50082-1, 89/336/EEC, AS/NZS 3548, CSA C108.8, and VCCI V-3. Individual WPIM Regulatory Compliance The following sections provide regulatory compliance standards for the WPIM-TI, WPIM-SY, WPIM-DDS, WPIM-E1, WPIM-DI, WPIM-S/T, and the WPIM-HDSL.
Page 245: Wpim-Sy
WPIM-SY This section describes the environmental speciﬁcations and safety and approval requirements for the WPIM-SY. This unit meets the safety requirements of UL1950, CSA C22.2 No. 950, EN 60950, Safety — IEC 950, and 73/23/EEC. This unit meets the EMI requirements of FCC Part 15, EN 55022, EN 50082-1, EMI —...
Page 246: Wpim-E1
Specifications and Standards Compliance WPIM-E1 This section describes the environmental speciﬁcations and safety and approval requirements for the WPIM-E1. This unit meets the safety requirements of EN 60950, IEC 950, 73/23/EEC and Safety — AS/NZS 3260. Electromagnetic Compatibility (EMC) — EN 50082-1, AS/NZS 3548, and 89/336/EEC.
Page 247 FCC Part 68 - User’s Information for CSX200 The following instructions are to ensure compliance with the Federal Communications Commission (FCC) Rules, Part 68: All connections to the WPIM-T1, WPIM-DI and WPIM-DDS must be made using standard plugs and jacks. Before connecting your unit, you must inform the local telephone company of the following information: Port ID...
Page 248 FCC Part 68 - User’s Information for CSX200 If the telephone company alters their equipment in a manner that will affect use of this device, they must give you advance warning so as to give you the opportunity for uninterrupted service. You will be advised of your right to file a complaint with the FCC.
Page 249 AFFIDAVIT FOR THE CONNECTION OFCUSTOMER EQUIPMENT TO 1.544 MBPS AND/OR SUBRATE DIGITAL SERVICES For the work to be performed in the certiﬁed territory of Telco’s name: State of: Country of: (Name of Authorized Representative) (Customer’s Address) being duly sworn, state: I have responsibility for the operation and maintenance of the terminal equipment to be connected 1.544 Mbps and/or terminal equipment to be connected complies with Part 68 of the Commission’s rules except for...
Page 250 FCC Part 68 - User’s Information for CSX200 I attest that the operator(s) maintainer(s) of the digital CPE responsible for the establishment, maintenance and adjustment of the encoded analog content and billing information has (have) been trained to perform these functions by successfully completing one of the following: Check appropriate one(s).
Page 251 Attachment Unit Interface. An IEEE 802.3 transceiver cable connecting the network AUI — device (such as a router) to the MAU (media access unit). Bandwidth on Demand — or closing multiple B channels) when the load in trafﬁc increases or decreases.
Page 252 Glossary Dynamic Host Conﬁguration Protocol is a protocol for automatic TCP/IP conﬁguration DHCP — that provides static and dynamic address allocation and management. Dial up WAN resources are accessed only when remote access is required Dial on Demand — and released as soon as the resource is no longer needed. Data Terminating Equipment.
Page 253 Glossary Integrated Services Digital Network. Digital transmission standard deﬁning ISDN — communication protocols permitting telephone networks to carry data, voice, fax and other streams. A telecommunications line between two service points leased from a Leased Line — communications carrier for private use, usually incurring a monthly service rate. Type of indicator lights on the panel of a device.
Page 254 Glossary Open System Interconnection. An international standard developed by ITU (formally OSI — CCITT) and ISO (International Organization for Standardization) to facilitate data networking multi-vendor interoperability. The OSI Reference Model deﬁnes seven layers, each providing speciﬁc network functions. A group of data that includes a header and usually user data for transmission through a Packet —...
Page 255 Glossary Simple Network Management Protocol. A widely implemented Internet network SNMP — management protocol that allows status monitoring, getting/setting of parameters for conﬁguration and control of network devices, such as routers and bridges. Each 64 Kbps ISDN B-channel can be used individually for a separate data Split B Channels —...
Page 256 Glossary Frames sent out by servers to clients, under IPX, to verify that clients are Watchdog Frames — still logged on. A communications network that is geographically dispersed thus Wide Area Network — requiring links provided by communications carriers. Computer or terminal used by the systems administration or user. Workstation —...
Page 257 Numerics 10BASE-T connection 22 impedance 21 length 21 requirements 21 temperature 22 Bootstrap Protocol Client 122 Bootstrap Protocol Server 122 Bridge ﬁltering 15 Bridge Setup bridge port pair administrative status 115 port administrative status 114 spanning tree protocol 114 Bridging 13 Bridging and routing 14 broadcast 124 Cable speciﬁcations...
Page 258 Index IEEE 802.3 Ethernet 9 about IP routing 14 Conﬁguring the Network Broadcast Type on a Port 124 Conﬁguring the UDP Broadcast Redirector 122 Enabling Forwarding on a Port 121 Enabling Proxy ARP on a Port 123 Enabling Routing Services on a Port 121 Enabling the RIP Routing Protocol on a Port 124 internet ﬁrewall 15...
Page 259 Safety Requirements 231 Selecting a Port for Conﬁguration IP 120, 128 SNMP 16 SNMP Community Names read-only 16, 43, 106 read-write 16, 43, 107 super-user 16, 43, 107 SNMP Traps enable traps 109 trap community name 108 trap destination 108 Software and ﬁrmware upgrades 20 Subnet Mask 102, 105 Sunrpc (NIS) 122...
Page 260 Index 246 CSX200 Family User’s Guide...
Page 261: Power Supply Cord
POWER SUPPLY CORD The mains cord used with this equipment must be a 2 conductor plus ground type with minimum 0.75 mm square conductors and must incorporate a standard IEC appliance coupler on one end and a mains plug on the other end which is suitable for the use and application of the product and that is approved for use in the country of application.
