To remove the chassis cover, proceed as follows:
1. Disconnect the CSX200 from the network as follows:
a. Unplug the power cord from the rear of the CSX200 chassis.
Before performing
associated port numbers. This is recommended for ease of reinstallation.
TIP
b. Disconnect all network cables attached to the CSX200.
2. Use a flat-blade screwdriver to remove the cover screw attaching the cover to the CSX200
chassis (refer to
3. Remove the cover by sliding it back until it clears the front of the chassis and then lifting it
straight up and off the chassis.
step b, mark any cables connected to the CSX200 according to their
Figure 4) and save the screw.
Chassis Cover
Figure 4 Removing the Plastic Chassis Cover
Chassis
Cover Screw (1)
